Specifications
diesel generating set1top qualty,factory price
2,380v,cummins generator set
3,single phase or three phase
diesel generating set
1top qualty,factory price
2,cummins generator set,220v/380v
3,single phase or three phase
diesel generator specification
| Model | WY-CM50(S) | ||
| Cont.AC outpu(KW) | 40 | 45 | |
| Max.output(KW) | 45 | 50 | |
| Voltage(V) | 380V,400V,440V | ||
| Frequency(Hz) | 50 | 60 | |
| Power factor | 0.8 | ||
| GENERATOR | Model | WY224D | |
| Cont.AC output(KW) | 40 | 45 | |
| Max.output(KW) | 45 | 50 | |
| Excitation SyStem | Brushless excitation | ||
| InSulation Class | H | ||
| ConStruction Type | SAE engine adaptor (single-bearing or double-bearing) | ||
| ENGINE | Model | 4BTA3.9-G2 | |
| Number of cylinders | 4L | ||
| Bore×stroke(mm) | 102×120 | ||
| Compression Ratio | |||
| Displacement(L) | 3.9 | ||
| Specific fuel consumption (g/kW.h) |
≤209 | ||
| Rated speed(r/min) | 1500 | 1800 | |
| Cont.output(kW) | 50 | 55 | |
| Max.outout(kW) | 55 | 60 | |
| Starting system | Electric | ||
| Cooling method | Closed circle water-cooled | ||
| Starting battery | 12V/120AH | ||
| Gensetfor protection | The protection of low accumulator,overspeed,high water temperature,low press-gas | ||
| ing time(h) | 12 | ||
| Overall dimensions(mm) | 2250*950*1150 | ||
| Package dimensions(mm) | 2350*1000*1220 | ||
| Net weight(kg) | 1120 | ||
| Dry weight(kg) | 1170 | ||
Optional Accessories of Diesel generator set
1. ATS (Automatic Transfer switch);
Which can start the diesel generator when the main power is off; when the main power comes back, it will shut down generator.
And ATS have the function of AMF (automatic Main power failure)
2. MCCB (Molded case circuit breaker);
It can protect the loading machine and the diesel generator.
3. Battery charger (float charger);
When the diesel generating set hasn’t been used for a long time, the batteries will be no power, in that way, you can’t start the generator. But the battery charger can charge the batteries from main power.
4. Extra daily fuel tank;
It will be requested while the base fuel tank capacity is not enough for daily fuel consumption.
5. Paralleling system;
This system can make several generators work together and automatically distribute the load according to set.
6. Remote Control Panel;
Which can control the generating set by computer, if use a RS484 or RS232 digital cable to connect the diesel generator to the computer.
7. Water separate (additional cooling system);
If the ambient temperature is too high, it will be harmful to the generating set. Fan and water cooling is not enough for radiate. The water separate system is much better for cooling, and the life of generator will be much longer.
8. Spare Parts of Cummins engine;
All the spare parts of each Cummins engine are supplied at very competitive price.
