Specifications
power diesel generator1top qualty,factory price
2, electric diesel generator
3cummins engine,single phase or three phase
power diesel generator
1top qualty,factory price
2 electric diesel generator
3cummins engine.single or three phase
4,50hz/1500rpm
disel generator specification
| Model | WY-CM50(S) | ||
| Cont.AC outpu(KW) | 40 | 45 | |
| Max.output(KW) | 45 | 50 | |
| Voltage(V) | 220/380 | ||
| Frequency(Hz) | 50 | 60 | |
| Power factor | 0.8 | ||
| GENERATOR | Model | WY224D | |
| Cont.AC output(KW) | 40 | 45 | |
| Max.output(KW) | 45 | 50 | |
| Excitation SyStem | Brushless excitation | ||
| InSulation Class | H | ||
| ConStruction Type | SAE engine adaptor (single-bearing or double-bearing) | ||
| ENGINE | Model | 4BTA3.9-G2 | |
| Number of cylinders | 4L | ||
| Bore×stroke(mm) | 102×120 | ||
| Compression Ratio | |||
| Displacement(L) | 3.9 | ||
| Specific fuel consumption (g/kW.h) |
≤209 | ||
| Rated speed(r/min) | 1500 | 1800 | |
| Cont.output(kW) | 50 | 55 | |
| Max.outout(kW) | 55 | 60 | |
| Starting system | Electric | ||
| Cooling method | Closed circle water-cooled | ||
| Starting battery | 12V/120AH | ||
| Gensetfor protection | The protection of low accumulator,overspeed,high water temperature,low press-gas | ||
| ing time(h) | 12 | ||
| Overall dimensions(mm) | 2250*950*1150 | ||
| Package dimensions(mm) | 2350*1000*1220 | ||
| Net weight(kg) | 1120 | ||
| Dry weight(kg) | 1170 | ||
♥Feature:
a. lowest fuel consumption
b.water cooled method
c. 1500speed ,low fault rate
d.low time maintenance
e.have own factory,insure for the quality,
f.weichai professional design
h. Customized exclusive your model,etc.
♦Alternators:
The alternators are world famous brands, Stamford,Marathon,Leory Somer or China alternators.There are optional equipments as listed bottom..
♥Apply to fuel:
diesel fuel
♣company :
Established in 2002, Fuan Wonyong Electrical Machinery Co.,Ltd is located in Dong Long Industrial Estate in the Motor City-Fuan, Fujian, China. Fuan Wonyong Electrical Machinery Co.,Ltd is specialized in manufacturing and exporting wide ranges of electromechanical products, covering Diesel generator set,Brushless Generators, Brushless Generating Sets,ST/STC, Stanford Generators, TFW2 Brushless TZH Excitation Series , etc. We have passed the international quality certification ISO9001-2000 and have attainted permission certificate of export and CE certification.
Wonyong always insists on the principle "Win By Quality, Serve Warmly" and makes efforts to develop new products to meet the market demand, providing high-quality products with competitive prices, offering timely and complete After-sales Service as we have a strong technical power, a sound scientific management and advanced inspection devices for a continuous improvement of products.
Fuan Wonyong Electrical Machinery Co.,Ltd has more than 100 clerks including 16 experienced and excellent Technical Engineers. With years of efforts, we are determined to develop our company into a large and powerful company. We sincerely hope to cooperate and establish stable business relationships with our clients from all over the world based on equality and mutual benefit. We warmly welcome you to visit our factory!
