35W Triple Output Voltage Switching Power Supply
US$ 24 - 25
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ILM
Model Number:
ILMSP-026
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
60W Quad Output Voltage Switching Power SupplyUS$ 25 - 26MOQ: 1000 Pieces -
85W Dual Output Voltage Switching Power SupplyUS$ 8 - 9MOQ: 1000 Pieces
-
104W Triple Output Voltage Switching Power SupplyUS$ 40 - 41MOQ: 1000 Pieces
-
Computer Switching Power Supply(single Output) 300WUS$ 10 - 11MOQ: 1000 Pieces
-
Computer Switching Power Supply 250WUS$ 8 - 9MOQ: 1000 Pieces
Place of Origin
Guangdong, China
Brand Name
ILM
Model Number
ILMSP-026
Output Power
1 - 50W
Output Type
Triple
Input Voltage
Other, 110V-240VAC
Output Voltage
5/12/-5VDC 5/12/-12VDC 5/15/-15VDC
Output Frequency
50/60HZ
Output Current
3A 1A 1.5A/5A 1A 1.5A/2.5A 1A 0.5A
Specifications
1. 3 years warranty2. 5~7 days delivery time
3. 90~260VAC
4. low price, good reliability
1. 3 years warranty
2. Low cost, High operating reliability at high temperature
3. Full range of input or input select by switch
4. Cooling by free air convection
5. Protections: Over-load, over-voltage, over-current, over-temperature, short circuit protections
6. LED indicator for power on
7.100% burn-in tests (at full load)
8.Design for easy heat-dissipating
9.Suitable for many types of LED lights, LED electronics screen, Industrial control products, instruments & equipements, safety-guard products, advertisements.
Model |
ILM-35T-1 |
ILM-35T-2 |
ILM-35T-3 |
ILM-35T-4 |
||||||||
Rated DC Output |
5V |
12V |
-5V |
5V |
12V |
-12V |
5V |
15V |
-15V |
5V |
12V |
24V |
Rated Current |
3A |
1A |
0.5A |
5A |
1A |
0.5A |
2.5A |
1A |
0.5A |
2.5A |
1A |
0.5A |
Rated Power |
29.5W |
33W |
35W |
36.5W |
||||||||
Input Voltage |
AC 85~264VAC 47-63Hz |
|||||||||||
Over-load protection |
150% (Fold back current limiting, recover automatically after problems removal) |
|||||||||||
Over-VoltageProtection |
130% (Hiccup mode, recovers automatically after faulty problems removal |
|||||||||||
Efficiency |
78% |
79% |
79% |
79% |
||||||||
Life Span |
50000hrs |
|||||||||||
MTBF |
250Khrs |
|||||||||||
Withstand Voltage |
I/P-O/P: 3KVAC, IP-FG:1.5KVAC, DC-FG:500VAC |
|||||||||||
Working-Temperature |
-10~60°C |
|||||||||||
Vibration |
10-500Hz, 2G 10min./1cycle, period for 60min, each along x, y, z axes. |
|||||||||||
Size (L*W*H) |
99*97*36mm |
|||||||||||
Packing |
0.36Kg/pcs, 45pcs/CTN |
|||||||||||
