Specifications
Cummins diesel generator1 high quality goods with factory price
2 Production line: diesel generator set :2kw~600kw
factory
Cummins diesel generator
1 high quality goods with factory price
2 Production line: diesel generator set :2kw~600kw
factory price Cummins perkins diesel generator
Our advantages:
1 Wide range:diesel generator ,gasoline generator ,alternator and rotary tiller.
2Our production line : generator set0.65kw~600kw ,including Cummins ,Perkins,Deutz ,Weifang engine,Stamford,Leroy somer alterantor .We have gasoline generator 0.65kw~8kw.
3Our Commitment:offering high quality ,moderate price with good after sale service.
4our goal:to be your long-standing and reliable suppler
5 excellent tech team with professional skills.
Fuan Wonyong Electrical Machinery Co.,Ltd Generator Set
Expert,Supply the Best Power Solutions!
Create For Better and Bright Life!
High Quality!!481KVA Marine Generator Cummins Engine
diesel generator specification
| Model | WY-CM38(S) | ||
| Cont.AC outpu(KW) | 30 | 33 | |
| Max.output(KW) | 33 | 36 | |
| Voltage(V) | 220/380 | ||
| Frequency(Hz) | 50 | 60 | |
| Power factor | 0.8/1 | ||
| GENERATOR | Model | WY184H | |
| Cont.AC output(KW) | 30 | 33 | |
| Max.output(KW) | 33 | 36 | |
| Excitation SyStem | Brushless excitation | ||
| InSulation Class | H | ||
| ConStruction Type | SAE engine adaptor (single-bearing or double-bearing) | ||
| ENGINE | Model | 4BT3.9-G2 | |
| Number of cylinders | 4L | ||
| Bore×stroke(mm) | 102×120 | ||
| Compression Ratio | |||
| Displacement(L) | 3.9 | ||
| Specific fuel consumption (g/kW.h) |
≤209 | ||
| Rated speed(r/min) | 1500 | 1800 | |
| Cont.output(kW) | 36 | 40 | |
| Max.outout(kW) | 40 | 44 | |
| Starting system | Electric | ||
| Cooling method | Closed circle water-cooled | ||
| Starting battery | 12V/120AH | ||
| Gensetfor protection | The protection of low accumulator,overspeed,high water temperature,low press-gas | ||
| ing time(h) | 12 | ||
| Overall dimensions(mm) | 2250*950*1150 | ||
| Package dimensions(mm) | 2350*1000*1220 | ||
| Net weight(kg) | 1080 | ||
| Dry weight(kg) | 1130 | ||
Warranty policy:
Guarantee for one year or 1500 hours (according to whichever reach first) from ex-factory date. During the guarantee period, our company will provide the free easy-damaged spare parts for problems caused by our quality of production or raw materials, except the damage caused by customer's incorrect manmade operation. After expiration, our company will provides cost spare parts maintenance for gen-set.
