Diesel generator
1sinlge or3 phase
2,1500/1800rpm
3.CE,ISO ,40kw
4silent type,380v,100%copper
Fuan Wonyong Electrical Machinery Co.,Ltd Generator Set
Expert,Supply the Best Power Solutions!
Create For Better and Bright Life!
High Quality!!Diesel Generator Cummins Engine
Specification
| Model | WY-CM50(S) | WY-CM57(S) | |||
| Cont.AC outpu(KW) | 40 | 45 | 45 | 50 | |
| Max.output(KW) | 45 | 50 | 50 | 55 | |
| Voltage(V) | 220/380 | 220/380 | |||
| Frequency(Hz) | 50 | 60 | 50 | 60 | |
| Power factor | 0.8 | 0.8 | |||
| GENERATOR | Model | WY224D | WY224E | ||
| Cont.AC output(KW) | 40 | 45 | 50 | 55 | |
| Max.output(KW) | 45 | 50 | 55 | 60 | |
| Excitation SyStem | Brushless excitation | Brushless excitation | |||
| InSulation Class | H | H | |||
| ConStruction Type | SAE engine adaptor (single-bearing or double-bearing) | SAE engine adaptor (single-bearing or double-bearing) | |||
| ENGINE | Model | 4BTA3.9-G2 | 4BTA3.9-G2 | ||
| Number of cylinders | 4L | 4L | |||
| Bore×stroke(mm) | 102×120 | 102×120 | |||
| Compression Ratio | |||||
| Displacement(L) | 3.9 | 3.9 | |||
| Specific fuel consumption (g/kW.h) |
≤209 | ≤209 | |||
| Rated speed(r/min) | 1500 | 1800 | 1500 | 1800 | |
| Cont.output(kW) | 50 | 55 | 50.0 | 55 | |
| Max.outout(kW) | 55 | 60 | 55 | 60 | |
| Starting system | Electric | Electric | |||
| Cooling method | Closed circle water-cooled | Closed circle water-cooled | |||
| Starting battery | 12V/120AH | 12V/120AH | |||
| Gensetfor protection | The protection of low accumulator,overspeed,high water temperature,low press-gas | The protection of low accumulator,overspeed,high water temperature,low press-gas | |||
| ing time(h) | 12 | 12 | |||
| Overall dimensions(mm) | 2250*950*1150 | 2250*950*1150 | |||
| Package dimensions(mm) | 2350*1000*1220 | 2350*1000*1220 | |||
| Net weight(kg) | 1120 | 1150 | |||
| Dry weight(kg) | 1170 | 1200 | |||
Engine Features:
1. 20kw-1000kw diesel engine
2. Multi-cylinder in-line or veer engine, 4-stroke, direct injection
3. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler
4. Machinery or electronic governing
5. Fuel injection pump
6. Electric motor starting system
7. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner
8. Low discharge, and low fuel consumption
Alternator Features:
1. World famous brand AC alternator: Leroy Somer, Stamford, Marathon,
2. Brushless, 4 poles, rotation magnet
3. IP21-23(NEMA1) CFClose is standard for all industrial alternators
4. H class insulation system
5. AVR self-regulated, voltage regulation rate: ≤±1%
6. Simple installation and maintenance with easy access to terminals, rotating diodes and coupling bolts
7. Wide range of flange adaptors and single bearing disc coupling
8. Radio interferCFCe restraining accords with the stipulation of VDE0875-N and ISO8528
