High Quality Rated Power 37.5kva/30kw Cummins Disel Generator

Name: High Quality Rated Power 37.5kva/30kw Cummins Disel Generator
Brand: wonyong
SKU: 108968397
Availability: InStock

US$ 1 - 50,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

wonyong

Model Number:

WY-CM50

Fuan Wonyong Electrical Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

fuzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name wonyong

Model Number WY-CM50

Output Type AC Three Phase

Speed 1500/1800rpm

Frequency 50/60hz

Rated Power 40kw

Rated Voltage 220/380v,400v

Rated Current other

Specifications

Cummins generator diesel
1goods is received well not only among customers,but also among fellow-manufacturers
2best price

Cummins generator diesel

1sinlge or3 phase
2,1500/1800rpm
3.CE,ISO ,40kw
4silent type,380v,100%copper

Fuan Wonyong Electrical Machinery Co.,Ltd Generator Set

Expert,Supply the Best Power Solutions!

Create For Better and Bright Life!

High Quality!!Diesel Generator Cummins Engine

Specification

Model		WY-CM50(S)		WY-CM57(S)
Cont.AC outpu(KW)		40	45	45	50
Max.output(KW)		45	50	50	55
Voltage(V)		220/380		220/380
Frequency(Hz)		50	60	50	60
Power factor		0.8		0.8
GENERATOR	Model	WY224D		WY224E
	Cont.AC output(KW)	40	45	50	55
	Max.output(KW)	45	50	55	60
	Excitation SyStem	Brushless excitation		Brushless excitation
	InSulation Class	H		H
	ConStruction Type	SAE engine adaptor (single-bearing or double-bearing)		SAE engine adaptor (single-bearing or double-bearing)
ENGINE	Model	4BTA3.9-G2		4BTA3.9-G2
	Number of cylinders	4L		4L
	Bore×stroke(mm)	102×120		102×120
	Compression Ratio
	Displacement(L)	3.9		3.9
	Specific fuel consumption (g/kW.h)	≤209		≤209
	Rated speed(r/min)	1500	1800	1500	1800
	Cont.output(kW)	50	55	50.0	55
	Max.outout(kW)	55	60	55	60
	Starting system	Electric		Electric
	Cooling method	Closed circle water-cooled		Closed circle water-cooled
	Starting battery	12V/120AH		12V/120AH
Gensetfor protection		The protection of low accumulator,overspeed,high water temperature,low press-gas		The protection of low accumulator,overspeed,high water temperature,low press-gas
ing time(h)		12		12
Overall dimensions(mm)		22509501150		22509501150
Package dimensions(mm)		235010001220		235010001220
Net weight(kg)		1120		1150
Dry weight(kg)		1170		1200
