JILONG KL300T Fusion Splicer Equal To Fujikura FSM70S Fiber Splicing Machine
US$ 1 - 2,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
JILONG
Model Number:
KL-300T
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Economical COMWAY Fusion Splicer Machine C8 as Good as Fujikura FSM-21SUS$ 3,000 - 3,800MOQ: 1 Unit -
COMWAY Fusion Solicer Machine C10/ The Most Featured ProductUS$ 4,000 - 4,600MOQ: 1 Set
-
COMWAY C10 / The Most Competitive Fusion Splicer TypeUS$ 4,000 - 4,600MOQ: 1 Set
-
ORIGINAL Fujikura Splicing Machine FSM-80S Latest Version in FujikuraUS$ 1 - 6,000MOQ: 1 Set
-
FUJIKURA FSM-70S Japan Fujikura 70s Fusion Splicer With CT-30 Cleaver Price Quality ChoiceUS$ 1 - 7,000MOQ: 1 Unit
Place of Origin
China
Brand Name
JILONG
Model Number
KL-300T
JILONG KL-300T Fusion Splicer Kit w/ Fiber Cleaver
Contact information
Mobile: 0086-13823128817
Tel:+86-755-36934393
Fax: 0086-755-33503470
Website: www..hk
Skype: kitty.hsv
The KL-300T Core Alignment fiber optic fusion splicer made by Jilong Communication is a solid reliable addition to any Technician’s tooling. In side by side specification comparisons the KL comes up first in more categories than the big three, Fujikura, Sumitomo or Fitel. The 300 triumphs in attributes like a 39 second splice/shrink cycle time, the second highest magnification on the market and lighter weight than all other standard fusion splicers.
But the KL-300T stands out even more with features that can’t be weighed & measured and put into a chart. Each and every time you interact with this machine you will appreciate features like a lighted fusion area, the largest screen on the market, a high resolution graphical user interface, easy to interpret universal buttons and frustration free menu navigation. Additionally when you see the video from the high resolution cameras you’ll know you’ve got a machine that will spoil you.
Features:
- Core to core alignment by PAS technology -(PAS:Profile Alignment System)
- Digital fusion splicer with automatic focus function
- Fiber core can be display clearly
- Single X or Y view and X & Y view simultaneously
- Auto detect cleaved endface fault
- Display fiber cleaved and offset angle
- Display core and clad offset
- 5.6 inch TFT color LCD monitor with clear digital image display
- USB & VGA interface
- Software upgrade via USB interface
Specifications:
Auto alignment: Yes
Splicing area viewing: Yes (2 CMOS cameras)
Splice loss assessment: Yes
Splicing mode: Auto, Normal, Special
Fiber cleaved angle threshold: 0.1 – 10.0, with a step of 0.1
| Model | KL-300T |
| Applicable fibers | SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655) |
| Fiber cleaved length | 8~16mm(Coating diameter:250um) 16mm(Coating diameter: 250 ~ 1000um) |
| Fiber diameter | Cladding diameter:80 ~150um Coating diameter:100~ 1000um |
| Fiber Count | Single |
| Fiber aligning method | Core or clad aligning |
| Image processing method | Digital |
| Actual average splice loss | 0.02dB (SM), 0.01dB (MM), 0.04dB (DS), 0.04dB( NZDS) |
| Splicing time | Typical 9 sec,with standard SM fiber |
| Splicing mode | 53(templet), 40(user) |
| Splice loss estimate | More accurate |
| Return loss | >60dB |
| Storage of splice result | 4000 results,20 parameter per result |
| Fiber display and magnification | 300X(X or Y view),150X(X and Y view) |
| Tube heating time | Typical 30 sec () |
| Tube heating mode | 9(templet), 24(user) |
| Tube heating temperature | Can be adjusted |
| Applicable Protection sleeve length | 60mm, 40mm and a series of micro sleeves |
| Tension test | 2N |
| Electrode life | 2500 |
| No.of splice/heating with battery | Typical 150 cycles (splice/tube heat) with inner Li-battery |
| Display screen | 5.6 TFT inch color LCD monitor |
| Image change over | The fiber image is turned upside down |
| Terminals | USB 1.1 and VGA |
| Operating condition | 0 ~ 5000m above sea level, 0 ~ 95%RH and -10~50C, respectively, Max. wind velocity of 15m/s |
| Power supply | AC 100-240V with AC adapter; inner Li-battery(6600mAH) |
| Dimensions | 150mm(L) x150mm (W) x150mm (H) |
| Weight | 2.7 Kg excluding battery,3.2 Kg including battery |
Included in the Package:
- 1. Jilong KL-300T Fusion Splicer
- 2. KL-31F/KL-21C High Precision fiber cleaver
- 3. Fiber Cleaver Carrying Case
- 4. CFS-2 fiber stripper
- 5. Internal rechargeable Li battery
- 6. AC adaptor
- 7. AC Power cord
- 8. USB Download Cable
- 9. Custom Hard Carrying Case
- 10. Spare electrodes
- 11. Cooling tray
- 12. Cleaning tools
- 13. Operating manual
