1.Advantages
1.simple and compact structure, reasonable design
2.high yield and easy maintenance
3.low energy consumption
JZ22 Brick making machine
JZ28 brick making machine:
Service policy:
1. Before sales: 1>the device type
2>for customer training and technical personnel
3>according to customer request, design and manufacture products
4> the company sent engineering and technical personnel to the user scene, planning for the optimal design of the flow field, and the solutions.
2. Medium-sales:1> Acceptance of the product
2> Assist client protocol construction scheme
3. After-sale
On-site training personnel
Appoint special after-sale service staff ,arrived at the scene guide clients installation and commission.
2.Technique
Professional excellent mechanical and kiln engineers, who can design perfect designing flowchart for the client to construct efficient and reasonable brick making production line.
3.Materials
Fly ash, Clay,Coal gangue, shale, high volume , urban construction waste, gangue waste, inferior soil.
4. Identification
We have Approval/certification for clay brick making machine:ISO9001:2008,GB/T 19001-2008.
5.Experience
We are one of the few brick machines manufacturing companies which appoint by the Chinese Brick&Tile Association. We have had some customers in India, Bangladesh and other countries, and even now we have helped one customer building the tunnel kiln in Bangladesh. And we sold many machines to Bangladesh, India, Nepal, Vietnam and other countries, and some of them even buy our machines twice or more. So we can promise you the good quality and perfect after-sale service .
6.Process
7.Contact information:
(JZ) Main technical data(JZ series)
|
|
Measuring unit |
JZ50/50-2.0 |
JZ45/45-1.5 |
JZ40/40-1.5 |
JZ35/35-1.5 |
|
Production capability |
/ standard brick packs/h |
18000-22000 |
16000-20000 |
14000-18000 |
12000-16000 |
|
Reamer diameter |
mm |
500 |
450 |
400 |
350 |
|
Extruding pressure |
(MPa) |
≤2.0 |
≤1.5 |
≤1.5 |
≤1.5 |
|
Forming liquid water content |
% |
18~22 |
18~22 |
18~22 |
18~22 |
|
Power |
(Kw) |
90~110 |
75~90 |
55~75 |
37~45 |
