UPVC Pipe Extrusion Machine

UPVC Pipe Extrusion Machine photo-1
US$ 25,000 - 90,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Pipe
Plastic Processed:
Other, PVC,UPVC,CPVC
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Pipe
Plastic Processed Other, PVC,UPVC,CPVC
Screw Design Double-screw
Automatic Grade Full-auto
Place of Origin Jiangsu, China
Brand Name BEIERMAN
Model Number SJZ
Voltage 220V/380V/415V, customerized
Power(W) according to the model
Dimension(L*W*H) according to the model
Weight according to the model
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

UPVC Pipe Extrusion Machine

UPVC Pipe Extrusion Machine

Screw Feeding Machine→ Hot and cool mixing unit → Spring feeding machine→ Conical Twin screw extruder → Mould and Calibration copper sleeve  → Vacuum calibration tank →   Hauling off machine  → cutting machine → Pipe stacker





 UPVC Pipe Extrusion Machine

UPVC pipe extrusion machine is mainly used to produce every size of pipe in the area of agricultural water supply system, architectural water supply system, pavement of cables, etc.

UPVC pipe extrusion machine consists of twin conical screws extruder, vacuum forming tank, haul-off unit, cutting unit, material tumbling frame, etc. twin screw extruder and haul-off unit adopt imported A/C inverter, both vacuum pump and driving motor used the first-class brand.



Model Screw Diameter(mm) Pipe Range(mm) Capacity(kg/h) Main motor power Total Power Line Length(m)
U-PVC63 51/105 16-63 80-120 18.5 50 22
U-PVC160 65/132 75-160 200-250 37 100 22
U-PVC250 65/132 110-250 200-250 37 120 30
U-PVC315 80/156 160-315 300-400 55 200 30
U-PVC450 80/156 200-450 300-400 55 220 36
U-PVC630 92/188 315-630 400-800 90 350 42



 UPVC Pipe Extrusion Machine

UPVC Pipe Extrusion Machine
