Cat5e RJ45 Keystone Jack

Product Feature

01. Much helpful for the easier and faster installation.
02. Its well match with Blank patch panels and Mounting boxes and Faceplates.
03. Cat. 5e is available.
04. Various colors are option.

Technique Characteristics:

1. Keystone Jack, Cat.5e, Tool-less Type,  for connecting application of communication ports in working area.

2. A compact & ingenious designing, with the punching sequence direction Marks on the sides of keystone jack. That can provide a correct and quick Guide for punching and connection operation. And the fastener hats will make sure the cable can be fixed reliably in the IDC clips.

3.According to the standard of ISO/IEC 11801: 2002 class & ANSI/TIA/EIA 568- B. 2-1 CAT. 5e, T568A punching sequence and T568B punching sequence are both compatible.

4. Connection type: FCC connector for RJ45 patch cord and IDC for 8-pair Cat. 5e cables.
5.Fitting for the Cat.5e general cable distribution system. Compatible for Cat. 5e systems.

Mechanical

1.  Housing material: PC UL94-V0

2. PCB material: FR-4 T=1.2mm

3.  Contact material: Phosphor bronze stamp PIN T=0.35mm

4. IDC Contact material: Phosphor bronze T=0.50mm WITH TIN PLATING

5. RJ45 JACK LIFE: 750 TIMES MIN

6. IDC LIFE: 200 TIMES MIN

7. WIRE: AWG 22~24

8. TIA CAT 5e PERM.LINK TEST: WORST PAIR NEXT MARGIN ≥3.0dB

9. Retentiveness of insertion structure: 50N 60±5s

Product Picture

Packaging & Shipping

Packing specification:

1.package:1pc/poly bag
2.Economic packing:500pcs per carton
3.N.W:7KGs G.W.:8KGs
4.MEAS:42*26*40CM

Shipping:

Sea, air, express shipment are available,it is based on your requestWe can help you get a good discount from EMS, Fedex,DHL, TNT, etc.

( Express shipment:We work with TNT,Fedex,DHL,UPS,etc. 60% Discount price, Fast service)

Delivery time: 3-5 working days

Payment:we accept Paypal,western union,T/T,and so on.

 Our service

· Your inquiry will be replied within 24 hours.
· Well-trained & experienced sales can reply your inquiries in English.
· OEM & ODM projects are highly welcomed.
· Your business relationship with us will be confidential to any third party.
· Good after-sale service.

Company Information

Ningbo Gloryal Electronic Technology Co.,Ltd. is a professional manufacturer in developing and producing all kinds of electronic items. Its leading products are telecommunication and network accessories,fiber optic products, network tool, HDMI series, solderless breadboard and room thermostat etc. It is located in Cixi City, 50km far from Ningbo seaport, and 2 hours to Shanghai. With prompt delivery, high-quality, nice-service, our goods have been exported to more than 30 countries.

Our Factory:

FAQ

We have worked out many high quality keyston jack,like Cat.6 STP Kyeston Jack,Cat.3 RJ12 Keyston Jack,Cat.5e RJ45 Keystone Jack and so on,also we can make products according to customers' requirements.

Service:
This Keystone Jack can be made according to your requirement.
- Excellent quality and reasonable price to provide.
- We do quotation within 2 days and welcome your any inquiry at any time.
- More details pelease call or email to us directly!

Why choose us?

1.Our factory are located in CIXI,abound of material and market resources, high quality, competitive price, best service.

2.We are a manufacturer who specialize in making network product for more than 8 years. our products are exported to USA, Europe country, Middle East , South America and so on.

3.Workflow: your idea →we make sample and send to you →you confirm and order →deposit →product →pay balance →shipment →After service

  Hope to receive your inquiry!
