Help CenterSMT Full Auto PCB Magazine Unloader
Related Products
-
SMT Full Auto PCB Magazine LoaderUS$ 1.00 - 1.00MOQ: 1 Set -
0.6m SMT Inspection Conveyor / Linkage Conveyor / Buffer ConveyorUS$ 1.00 - 1.00MOQ: 1 Set
-
SMT Conveyor/ SMT Linkage/ SMT Inspection ConveyorUS$ 1.00 - 1.00MOQ: 1 Set
-
PCB Conveyor for PCB SMT Production LineUS$ 1.00 - 1.00MOQ: 1 Set
-
Glue Dispenser/Automatic Glue Dispenser Machine/SMT MachineNegotiableMOQ: 1 Set
Main functions and Parameter:
Name |
Automatic Unloader |
Model |
ULD-400B |
Dimensions(L*W*H) |
1950*680*1650mm |
Magazine dimensions(L*W*H) |
340*300*570mm |
PCB size |
60(L)×60(W)mm--400(L)×390(W)mm |
Air Source |
4-6MPa |
Power Source |
220v 50HZ |
Working power |
0.25KW |
Adjustable Lifting distance |
10,20,30,40 and 50mm |
Direction |
L-R/ R-L |
1.Special Aluminum alloy guide rails and rubber belt.
2.Magazine lifting with screw rod by 90WSPG electric-brake motor.
3.Pneumatic PCB clamping structure .
4.Programmable Siemens PLC and controller.
5.PCB Automatic unloading to conveyor.
6.Touch Panel controlled interface/Buttons interface.
Features:
1.Micro computer controlled component ensures machine’s stable and reliable running.
2.Optional Fuji buttons interface or touch panel interface, convenient man-machine interaction.
3. Multiple sound and light alarming functions
4. Use standard magazines, good compatibility, load with 3 magazines at one time.
5. Lifting distance adjustable according to PCB, 4 kinds of distance(10mm, 20mm, 30mm and 40mm)
6. Unloader configured with inner push board component, save the cost of buying PCB moving machine independently.
7. Automatic counting function make it easy of production statistic
8. Optional SMEMA port for communication between machines.
