Shenzhen Jaguar Automation Equipment Co., Ltd is a High-speed developing enterprise of high Precision Automation Lead -free Equipments such as reflow oven, wave soldering machine, solder paste printer, PCB conveyor ect. manufacturer, which specializes in lead free machines’ research and development.
At present, we have researched and developed 4 sorts of environmental friendly reflow oven, there are A series, M series, F series and R series. What's more, we have also develop wave soldering machine, for example, the econimic wave solder, top lead free wave solder and high-end of large size wave solder. All of our machines are not only used wildly in electronic circuit, LED industry, instruments and apparatuses, but also in household appliances, such as washing machine, microwave, television ect.
Main characteristics:
1. Special for Dispensing T8 LED Tube, 6 tubes can be worked at the same time, the production can reach 400 pcs/hours.
2. The tube length can be 1200mm, 600mm and 900mm also available.
3. The dispensing head individually controlled,you can chose which to dispense and which one donot.
4. control systems operate using touch screen.
5. All the control parameter can be adjusted by the screen.
Specification:
| Work area | Max<=1200mm |
| Travel speed | Max<=500mm/sec |
| Repeatability precision | ±0.05mm |
| Source of power | Compressed air and auxiliary cylinder |
| Glue capacitance | 2600ml |
| Glue viscosity | max<=20000cps |
| Control method | PLC & screen |
| Programming method | Teaching programming |
| Program capacity | At least 100 groups,4000 points/group |
| Drive mode | Stepping motor, mesh, and linear guide rail |
| Input pressure | 0.5-0.8MPa |
| Supply power | AC220V 50HZ / 2000W |
| Operation environment | Humidity:20-90% Temperature:0-40ºC |
| Machine size(W*D*H) | 3200*750*1550mm |
| Weight | About 300kg |
Glue type: 2600ml single component silicone
