Machine for 200L Double Ring Drum

Name: Machine for 200L Double Ring Drum
Brand: longhua
SKU: 108856993
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Bottle

Plastic Processed:

Other, PE\ABS\PVC...

Zhangjiagang Longhua Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Bottle

Plastic Processed Other, PE\ABS\PVC...

Blow Moulding Type Extrusion Blow Moulding

Automatic Yes

Place of Origin Jiangsu, China

Brand Name longhua

Model Number LHB120N

After-sales Service Provided Engineers available to service machinery overseas

Specifications

machine for 200L double ring drum
1.MAX container capacity 300L
2.Machine dimension:6.8M*3.3M*5.2M
3, 8kg to 12kg , HMW HDPE

machine for 200L double ring drum
1.MAX container capacity 300L
2.Machine dimension:6.8M*3.3M*5.2M

3.Machine weight :3.5T

Technical Specification

Item	Code item	Standard code	Manual	Note
Extruder (Main extruder )	Max capacity	250L
	Main screw	Ø120mm	High efficiency mixing
	Screw L/D	25-30
	Screw material		38CrMoALA
	Max.Extruder consumption	200-280KG/hr
	Twisting transition method	Electrical machinery, Gear box, AC motor	Hard gear surface decelerator with AC regulator
	Driving motor	75KW
	Screw rotate speed	5-60r/min
	Ahead/back adjusting	Yes
	Up/ down adjusting	Yes
	Temperature control zone	5
	Heating power	15kw
	Cooling for blower	5
	Cooling function	Yes	Cooling water
