P10 Dip Outdoor RGB Led Screen Module

Name: P10 Dip Outdoor RGB Led Screen Module
Brand: P10 Outdoor Full Color
SKU: 108793901
Availability: InStock

Dongguan Deying Photoelectric Co., Ltd.

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

P10 Outdoor Full Color

Model Number:

DY-P10, DY-AP10

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name P10 Outdoor Full Color

Model Number DY-P10, DY-AP10

Usage Other, Outdoor, Outdoor

Tube Chip Color Full Color

Display Function Other, Video, Video

Pixels Other, 10mm, 10mm

Screen Dimension 160mm*160mm

Specifications

Model Number: DY-AP10
Display Function: Video
Tube Chip Color: Full Color
Brightness:7000-8000cd/sqm
Warranty: 2years

Specifications

P10 led display module
1.High brightness P10 module
2. Long life span led module
3. 15 month warranty
4. CE&RoHS certificate

Long lifespan P10 outdoor full color led display module

Specification:

Module size	160mmx160mm
Module resolution	16dots x 16dots
Configuration	1R1G1B
Viewing Distance	≥10M
Ingress protection front/rear	IP65/IP54
Control Manner	1/4
Drive Method	Constant current
Viewing angle	H:110° V:55°
Operating Humidity	10~99%
Storage Humidity	10~99%
Refresh Rate	>= 400 Hz
Life Time	100000 hrs
Certificates	UL CE ROHS CCC
Working Voltage	220/110 VAC 50/60 Hz
The Greatest Consumption	<=1000 W/m2
Working Environment Temperature	-20°C~65°C
