Low price P5 Indoor RGB LED display Module

FOB Price

USD $13 - $20 / Piece

100 Pieces(Min.Order)

Supply Ability 5000 Square Meter / Square Meters per Month
Port shenzhen
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	HCM/OEM	Model Number:	P5SMD
Usage:	Indoor	Tube Chip Color:	Full Color	Display Function:	Video
Pixels:	Other, 5mm	Screen Dimension:	Customized

Product Description

Indoor Fixed LED Display Screen

Outdoor Fix LED Display Screen

LED Stage rental display screen

Product Description

Low price P5 Indoor RGB LED display Module:

1)High cost performance.

2) Good Consistency and High resolution.

3)High brightness and refresh rate .

4)Good after-sale services.

5)In the premise of guaranteeing quality,our company sales at low profit and warranty for 3 years.

Indoor Fixed Screen

	P3	P4	P5	P6
Pixel Pitch	3mm	4mm	5mm	6mm
Module Size	192mmx192mm	256mmx128mm	320mmx160mm	384mmx192mm
Module Resolution	64x64dots	64x32dots
Pixel Density	111,111 dots/sqm	62,500 dots/sqm	40,000 dots/sqm	27,777 dots/sqm
Minimum Viewing Distance	3m	4m	5m	6m
Brightness	1,500nits	2,000nits	1,800nits	1,500nits
Grey Scale	16384 level
Color Number	68.7194billion
Display Mode	Synchronous with video source
Refresh Rate	≥1920Hz
Driver IC	MBI5124/MBI5020
Drive Mode	1/32 scanning, constant current	1/16 scanning, constant current
Viewing Angle	Vertical 140° Horizontal 120°
Temperature Range	-20℃ to +60℃
Ambient Humidity	10%-99%
Service access	Rear
Power Consumption	Max: 905 w/sqm; Average : 300w/sqm	Max: 1020w/sqm; Average : 320w/sqm	Max: 650 w/sqm; Average : 220w/sqm	Max: 450 w/sqm; Average : 160w/sqm
Protection Level	Front: IP43 Rear: IP43
Lifetime to 50% brightness	75,000hr
LED Failure Rate	<0,00001(Led display line standard <0,0001)
MTBF	> 100.000 hours
Input power cable	AC110V / 220V
Certification	CCC,ROHS,CE
Warranty	2 Years quality warranty

Our Company

Shenzhen hechuang Mei Optoelectronics Technology Co., Ltd. is a professional high-tech manufacturer engaged in LED display and peripheral products R & D, production, sales and service in one. Companies rely on advanced management mode, strong R & D and excellent technical ability and rich in raw materials supplier chain, to produce high quality products, the company spent more than 6 years of time, carefully built a professional platform for a modern enterprise. The company sells according to market demand, industrial chain business model, has formed a complete advanced system of production, is one of the fastest development high-tech enterprises in domestic industry and the world's.

Packing & Delivery

Certifications

Contact Us

Shenzhen Hechuangmei Opto-Electronics Technology Co., Ltd.: Contact nameTony Cheung; Phone86-755-29100391; AddressBuilding 3, Lezhujiao Tianfu'an Industrial Park, Bao'an District Shenzhen,Guangdong
