P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10

P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10 thumbnail-1
P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10 thumbnail-2
P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10 thumbnail-3
P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10 thumbnail-4
P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10 thumbnail-5
P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10 thumbnail-6
P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10 photo-1
P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10 photo-2
P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10 photo-3
P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10 photo-4
P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10 photo-5
P10 Led Display Outdoor Full Color RGB Module for Module Led Full Color P10 photo-6
US$ 13 - 15 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
P10 Outdoor Full Color
Model Number:
DY-AP10, module led full color p10
Contact Supplier Request Quote Chat Now
Dongguan Deying Photoelectric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name P10 Outdoor Full Color
Model Number DY-AP10, module led full color p10
Usage Other, Outdoor, Outdoor
Tube Chip Color Full Color
Display Function Other, Video, Video
Pixels Other, 10mm, 10mm
Screen Dimension 320mm*160mm

P10 led display outdoor full color RGB module for module led full color p10

Specification:









Outdoor P10 DIP Full Color LED Display Screen
No.         Item          P10
1 Pixel pitch  10mm
2 Module size  320mm*160mm
3 Module resolution(dots) 32*16
4 Pixel configuration 1R1G1B
5 Pixel density 10000dots/m²
6 Red wavelength 625±2nm
7 Green wavelength 525±2nm
8 Blue wavelength 470±2nm
9 Colors 16777216
10 Best viewing distance ≥10m
11 Horizontal view angle 120°
12 Maximum power consumption <1500W/m²
13 Brightness ≥7500cd/m²
14 Gray scale 16 bits per color
15 Color temperature 6500k
16 Control method Synchronization&Asynchronization
17 Driving method 1/4 scanning
18 Frame frequency 60Hz
19 Refresh frequency ≥300Hz
20 Working voltage AC220V/110V±10%
21 IP grade IP 67
22 Working temperature -20°C~80°C
23 MTBF >10,000 hours
24 Life span >100,000 hours









 P10 led display outdoor full color RGB module for module led full color p10











 P10 led display outdoor full color RGB module for module led full color p10















P10 led display outdoor full color RGB module for module led full color p10
