Hot Product 32*16 Red P10 LED Electronic display Module

Description

Technical parameter

Unit module

Module size

320*160mm

Pixel pitch

10mm

Pixel density

10000dots/m2

Pixel configuration

1R

Led specification

546

Pixel resolution

W:32dots*H:16dots

Cabinet

Dimension

960mm*960mm*150mm

Quantities of module

18pcs

Power supply

4pcs

Thermal discharge

Fan*2pcs

Total weight

50kg

Best viewing angle

10-300m

Temperature

Storage: -35°C~+85°C

Working: -35°C~+85°C

Thickness

15cm can adjustable

Remarks: cabinet size can changed, upon project need.

Power

Working voltage

AC220V/110V±10%

Average power consumption

100-150W

Max. Power consumption

≤200-300W/sqm

Current

≤20mA(single LED)

Control system

CPU

Pentium4 or above

Operating system

WIN98/2000/NT/XP

Control method

Synchronization

Main technical parameter

Driving device

1/4 scanning

Drive type

Constant Current driver IC

Refresh frequency

≥600Hz

Grey scale/colors

256 levels of each color(R/G/B)/16.7M color

Brightness of white balance

More than 2500cd/sqm

Brightness adjustment

256 levels of each color(R/G/B)by software

Operating ambient humidity

10%--65%

Video signal

PAL/NTSC

Control system

DVI display card+full color controller card

MTBF

≥10,000hours

Life span

≥100,000hours

Flatness

Tolerance of interpixel ≤0.3mm

Tolerance of modules clearance≤0.6mm

Power switch

Automatic switch

Display mode

1024*768

Communication distance

Unshielded twisted pair net line transmission distance 100m, max transmission distance 200m.

Multi-mode Optic fiber transmission distance 500m;Single-mode optic fiber transmission distance 10KM

Software

LED media player
