Line Type Lightning Arrester With Gap

Name: Line Type Lightning Arrester With Gap
Brand: Mingneng
SKU: 108745127
Availability: InStock

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Mingneng

Model Number:

HY5CX-51/134E

Wenzhou Mingneng Electrical Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Mingneng

Model Number HY5CX-51/134E

Specifications

R.V:51KV
material: ZnO varistor, silicon rubber housing
certification:ISO9001:2008
confirm to IEC60099-4
Offer OEM & ODM

Product's characteristics:

good sealing performance, special structure, anti-moisture and anti-explosion
its performance in heat-release and ability to absorb over-voltage is good
small volume, light weight, flexible installation, collision-resisting, high pull-resisting intensity, no breakage during transportation
it apply to: transmission line that with low thunder withstand and high lightning trip rate; dry hilly and mountain; tower with high earth resistance; heavy polluted area.

Technical Parameter:

Normal service conditions:

1.The ambient air temperature is no higher than +40 degree. no lower than -40 degree.

2.The altitude above sea level does not exceed 2000m

3.Power frequency 48Hz~62Hz

4.Maximum wind speed does not exceed 35m/s

5.The earthquake intensity does not exceed 7 degrees
