Needle Flame Test Apparatus
SPECIFICATION
IEC60695-11-5 UL746A GB/T5169.5-2008, GB4706.1-2005..
FEATURES
With predetermined size (Φ 0.9 mm) needle burner, in 45°angle burning product, measure the fire risk by product lightoff or hold burning time . Used for lighting, low voltage electric appliance, household appliances, electric machine, motor, electric toolselectrical instrument, electrical connector such as electrical and electronic equipment and parts, components of research,production and quality inspection department, also suitable for insulation materials, engineering plastics.
TECHNICAL DATA
Needle burner |
inner hole diameter Φ 0.5mm ± 0.1mm, Diameter,9mm≤Φ, length ≥ 35mm, stainless steel |
Burner angle |
0,°20°, 45° (adjust flame height) |
Flame Gas |
butane gas/Butane gas, min. 95% purity (can use bottled lighter gases) |
Temperature Test Range |
0~1000°C |
Flame Temperature Requirements |
from 100 °C ± 2 °C liters to 700 °C ± 3 °C time in 23.5 seconds ± 1 seconds |
Standard Copper Block |
4mm±0.01mm, weight.0.58g±0.01g before drilling. Cu-ETP |
Test process |
automatic control, independent convulsions |
Chamber |
≥0.5m3 |
Size |
W1100mm×D700mm×H1300mm, exhaust hole Ø100mm |
Control |
Using single chip microcomputer + touch screen control |
Consult standard |
GB/T5169.10-2006 , IEC60695-2-10:2000,UL746A |
Power Supply |
800VA ,220V, 48-60Hz |
Display panel language |
Chinese + English (adjustable) |
PACKING Wooden Case
Shipping Method Express/By Air/By Sea
Company profile
AUTOSTRONG is a reputed manufacturer of Laboratory safety test equipments and has engaged
in Research & Development and Manufacture test equipments for many years. All our products
are strictly designed and manufactured in accordance with IEC,CE,EN,VDE,ASTM,ISO and other
international standards.
If you still have question,please feel free contact me.
