Help CenterZ5032A Vertical Drilling Machine
Related Products
-
LF Mini Drill Machine,small Manual Drilling MachineUS$ 1,500 - 2,200MOQ: 2 Sets -
Z4050 Small Drilling Machine,manual Drilling MahineUS$ 2,150 - 2,650MOQ: 1 Set
-
Z5032A Vertical Drilling MachineUS$ 2,300 - 2,650MOQ: 2 Sets
-
Z4640 Multi Spindle Combination Drilling Machine,two Heads Drilling MachineUS$ 8,500 - 9,500MOQ: 2 Sets
-
Z4040 Normal Drilling Machine,manual Drilling MahineUS$ 4,000 - 5,000MOQ: 2 Sets
Specifications
Aishi machine is perfect for mass producing and training purpuses. manual drilling machine,z5035 drilling machine.Z5032A Manual Driling Machine
· Z5032A drilling machine is featured in large journey with a wide range of processing capability. capable of fulfilling the tasks such as boring,broaching and reaming.The boring and milling acpability of the machine is unique.
·Z5032A drilling machine enjoys flexible speed adjustment method.To adjust the speed,simply open the case and loose the handle.
·The feeding system can be operated by means of auto and manual.The automatic feeding is Stepless variable speed,which can be flexibly adjusted by the operator.Thus,the process efficiency is effectively raised.
·The stroke mechanism is another patent of the enterprise,which combines the rig-adjusting and fine-adjusting,rusulting in convenient operation and esthetic appearance. milling drilling machine
| MODEL | Z5032A |
| CAPACITY | |
| Drilling capacity(max.) | Ø32mm |
| SPINDLE | |
| Spindle taper | MT4 |
| Spindle speed | 82-3240rpm |
| Spindle speed steps | 12 |
| Distance spindle-column | 235mm |
| SPINDLE HOLEING FIXTURE | |
| Z-axis travel | 150mm |
| Rate of feed/Torque motor Z-axis | Auto |
| COLUMN | |
| Column diameter | Ø120mm |
| TABLE | |
| Table (L×W) | Ø340mm |
| Table load | 100kg |
| Distance spindle-middle table(max.) | 575mm |
| Distance spindle-base table(max.) | 1145mm |
| ELECTRIC SUPPLY | |
| Motor | 1.5kW |
| Speed regulating motor | 75T/50T/30T/18T |
| Motor coolant pump | 40W |
| DIMENSION AND WEIGHT | |
| Overall dimension (L×W×H) | 820×520×1860mm |
| Packing size (L×W×H) | 650×960×2000mm |
| Net weight/Gross weight | 400kg |
