Z5040A Manual Drilling Machine,vertical Drilling Mahine
US$ 3,800 - 4,700
MOQ: 2 Sets
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Drilling Speed:
67-1780rpm
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai / ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
CNC or Not
Normal
Drilling Speed
67-1780rpm
Place of Origin
Zhejiang, China
Brand Name
Aishi
Model Number
Z5040A
Voltage
220/380V
Power(W)
2.2/2.8Kw
Dimension(L*W*H)
8000x1240x2150mm
Weight
650kgs
Certification
ISO
Specifications
Drilling capacity(max.) :40mmSpindle taper :MT4
Spindle speed:67-1780rpm
Distance spindle-column:350mm
Z-axis travel:180mm
Z5040A Manual drilling machine,vertical drilling mahine
| MODEL | Z5040A |
| CAPACITY | |
| Drilling capacity(max.) | Ø40mm |
| SPINDLE | |
| Spindle taper | MT4 |
| Spindle speed | 67-1780rpm |
| Spindle speed steps | 12 |
| Distance spindle-column | 350mm |
| SPINDLE HOLEING FIXTURE | |
| Z-axis travel | 180mm |
| Rate of feed/Torque motor Z-axis | 0.1,0.2,0.3mm/r |
| COLUMN | |
| Column diameter | Ø156mm |
| TABLE | |
| Table (L×W) | 520×400mm |
| Table load | 100kg |
| T-slot | 14mm/2 |
| Distance spindle-table(max.) | 535mm |
| ELECTRIC SUPPLY | |
| Motor | 2.2/2.8kW |
| Motor coolant pump | 40W |
| DIMENSION AND WEIGHT | |
| Overall dimension (L×W×H) | 960×600×2250mm |
| Packing size (L×W×H) | 800×1240×2150mm |
| Net weight/Gross weight | 650kg |
