Specifications
Aishi machine is perfect for mass producing and training purpuses Two head Drilling MachineZK4640 Two head Drilling Machine
· ZK4640 cnc drilling machine,an electromechanical integration design ensures the compact structure and esthetic appearance;
· The feed for spindle transmission system of ZK4640 cnc drilling machine uses the high accuracy ball bearing guide screw,the localization is precise,the precision stability is good,specially using in the blind hole decides the deep precision high work piece;
· The feeding is realized by means of CNC system,capable of realizing a cycle comprising fast forward→ fine forware→ fast backward(chip removal),the efficiency prominently improved. In addition,an orders are designed specifically for drilling operation,which simplifies the operation and improves the effectiveness ;
· According to user is requirements,it can change from drilling to tapping,from drilling to milling,cutomatic to manually,and install of multiaxial. That can reduce time,change processes,improve work efficiency.
| MODEL | ZK4640 |
| CAPACITY | |
| Drilling capacity(max.) | Ø40mm |
| ACCURACY | |
| Repeating accuracy | 0.015mm |
| Positioning accuracy | 0.025mm |
| SPINDLE | |
| Spindle taper | MT4 |
| Spindle speed | 67-1780rpm |
| Spindle speed steps | 12 |
| Distance spindle-column | 350mm |
| Distance between two columns | 500mm |
| SPINDLE HOLEING FIXTURE | |
| Z-axis travel | 200mm |
| Rate of feed/Torque motor Z-axis | 0-5000mm/min |
| COLUMN | |
| Column diameter | Ø165mm |
| TABLE | |
| Table (L×W) | 1070×400mm |
| Table load | 200kg |
| T-slot | 14mm/100mm/3 |
| Distance spindle-table(max.) | 600mm |
| ELECTRIC SUPPLY | |
| Motor | 2.2/2.8kW |
| Motor coolant pump | 40W |
| DIMENSION AND WEIGHT | |
| Overall dimension (L×W×H) | 1400×1400×2400mm |
| Packing size (L×W×H) | 1570×1480×2000mm |
| Net weight/Gross weight | 2000kg |
