High Intensity SMC Combined Water Tank For Hotel Using

Standard export package/Wooden case/Steel frame/Pallet for for SMC combined water tank or as customer require

High Intensity SMC Combined Water Tank For Hotel Using

SMC Combined Water Tank Introudction

It is composed of SMC mould compressed plate, sealing material, metal structural part, and fittings. It is site installed, which gives great convenience for design and construction. We can design the water tanks from 0.125 to 1500m3. If the original water tank needs to be replaced, it will not need to reform the housing. Good adaptability. Specially researched sealing strip, which is non-toxic, water resistant, long elasticity, small permanent deformation; tightly sealing. High integral strength; easy for maintenance and inspection

SMC Combined Water Tank Physical and Chemical Function

SMC Combined Water Tank Application

1). Potable drinking water storage

2). Rainwater storage

3). Emergency water Storage

4). Pump chambers

5). Hospital, buildings, building site, school and other place

SMC Combined Water Tank Assembly

Step 1. Install steel footings on leveled concrete foundations.
Step 2. Align GRP panels to be pre-assembled.
Step 3. Place rubber sealant from ready-to-use roll between panels.
Step 4. Connect panels with bolts and nuts.
Step 5. Position bottom panel sections, and finish up base of tank.
Step 6. Position three sides of the tank.
Step 7. Position and fix top panels and if required, top support pipes and plates.
Step 8. Install reinforcement if required.
Step 9. Close up the tank with the fourth side.
Step 10. Finish the internal or external reinforcement.
Step 11. Fill and test.
