Good Quality & Low Price! Auto-Scan Laser Handheld Bar Code Scanner Sumlung SL-7900 USB Port

Model No.

SL-7900

OPERATIONAL

Light Source

650 nm Visible Laser Diode

Scan pattern

Single Line

Depth of Field

10 - 450 mm (PCS0.9, density0.25)

Width of Field

60 mm at 30 mm, 98 mm at 100 mm

Scan Rate

100 scans/sec

Minimum Bar Width

0.1 mm (4 mil) (Code 39, PCS=90%, contact)

Scan Distance

10 - 820 mm

Print Contrast

30% @ UPC/EAN 100%

Roll

± 30°

Pitch

± 65°

Skew

± 55°

Indicators

Bicolor LED

Beeper

Adjustable audio and volume

Decode Capability

UPC, EAN, JAN, EAN128, Code 39, Code 39 Full ASCII, Code 11, Matrix 25, Interleaved 25, Industrial 25, Codabar/NW7, Code 93, MSI/PLESSEY, Code 26, Code 32, LCD 25, Telepen, GS1 DataBar, China Postage

PHYSICAL

Dimensions

L*W*H  166 × 66 × 86 mm (device only)

Weight

158 g (w/o cable)

Cable

1.8 meters

Material

ABC & RUBBER (RoHS)

REGULATORY

EMI

Conform EN50081, par1 standard

Avoid EMI

Conform EN50082, par1 standard

Dust-proof and waterproof

Conform IEC529, IP42 standard

EMC

CE & FCC DOC compliance, GB Laser Safety Class 2

ENVIRONMENTAL

Operating Temperature

0°C - 45°C (32°F - 113°F)

Storage Temperature

-20°C - 60°C (-4°F - 140°F)

Humidity

5% - 85% RH (non-condensing)

Light Levels

Sunlight Max. 4,000 Lux

Drop Durability

Designed to withstand 1.5 M drops

WARRANTY

One year
