Help CenterAuto-Scan Desktop Laser Bar Code Scanner Sumlung SL-7900 USB Port Handheld With Stand
Related Products
-
Champ CCD Barcode Scanner SD100 USB RS232 KeyboardNegotiableMOQ: 10 Units -
Champ CCD Barcode Scanner SD313ENegotiableMOQ: 10 Units
-
Champ Handheld CCD Barcode Reader SD500 USB RS232 PS2 Port#8019NegotiableMOQ: 10 Units
-
Barcode Scanner Honeywell MS9520NegotiableMOQ: 10 Units
-
Hand-held Barcode Scanner Honeywell MS9540NegotiableMOQ: 10 Units
Specifications
Hands FREE! Auto Scan! USB cable with Stand! Great barcode scan ability! Factory warranty! Laser Barcode Scanner Sumlung SL-7900Auto Scan Hands Free Laser Barcode Scanner Sumlung SL-7900
USB interface, with Stand
Specifications
Model No. |
SL-7900 |
OPERATIONAL |
|
Light Source |
650 nm Visible Laser Diode |
Scan pattern |
Single Line |
Depth of Field |
10 - 450 mm (PCS0.9, density0.25) |
Width of Field |
60 mm at 30 mm, 98 mm at 100 mm |
Scan Rate |
100 scans/sec |
Minimum Bar Width |
0.1 mm (4 mil) (Code 39, PCS=90%, contact) |
Scan Distance |
10 - 820 mm |
Print Contrast |
30% @ UPC/EAN 100% |
Roll |
± 30° |
Pitch |
± 65° |
Skew |
± 55° |
Indicators |
Bicolor LED |
Beeper |
Adjustable audio and volume |
Decode Capability |
UPC, EAN, JAN, EAN128, Code 39, Code 39 Full ASCII, Code 11, Matrix 25, Interleaved 25, Industrial 25, Codabar/NW7, Code 93, MSI/PLESSEY, Code 26, Code 32, LCD 25, Telepen, GS1 DataBar, China Postage |
PHYSICAL |
|
Dimensions |
L*W*H 166 × 66 × 86 mm (device only) |
Weight |
158 g (w/o cable) |
Cable |
1.8 meters |
Material |
ABC & RUBBER (RoHS) |
REGULATORY |
|
EMI |
Conform EN50081, par1 standard |
Avoid EMI |
Conform EN50082, par1 standard |
Dust-proof and waterproof |
Conform IEC529, IP42 standard |
EMC |
CE & FCC DOC compliance, GB Laser Safety Class 2 |
ENVIRONMENTAL |
|
Operating Temperature |
0°C - 45°C (32°F - 113°F) |
Storage Temperature |
-20°C - 60°C (-4°F - 140°F) |
Humidity |
5% - 85% RH (non-condensing) |
Light Levels |
Sunlight Max. 4,000 Lux |
Drop Durability |
Designed to withstand 1.5 M drops |
WARRANTY |
|
|
One year |
