Champ CCD Barcode Scanner SD313E

Specifications

Champ CCD Barcode Scanner:SD313E Feature:
Scan speed 100 times/s
Scan width 8 centimetre
Read 0-20mm

Barcode scanner shamp SD313E



Cost-effective model SD-313E red CCD



Red scanner type   (CCD)



Material ABS plastic computer shell white



660nm LED light source



Scan speed 100 times / sec



Scan range 0 ~ 25mm



Work environment 0 to 50 degrees Celsius (32 ~ 104 degrees F)



Output interface PC keyboard port, USB interface, optional



Input Voltage +5 V DC ± 5%



Contrast Contrast> = 30%



1.5 m free-fall wrestling shock resistance (concrete floor)



Body weight of 200 grams



Scan width 82mm



Scan Density 0.100mm (4mil)
