Paper Cup Production Machine

Paper Cup Production Machine thumbnail-1
Paper Cup Production Machine photo-1
US$ 25,000 - 35,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Paper Cup Machine
Processing Type:
Printing Machine
Contact Supplier Request Quote Chat Now
Ruian APT I/E Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Product Type Paper Cup Machine
Processing Type Printing Machine
Place of Origin Zhejiang, China
Brand Name APT MACHINERY
Model Number APTD-12/22
Voltage 380V/440V
Power(W) 9KW
Dimension(L*W*H) 2.8*1.6*1.6M
Weight 2500KG
Certification CE
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Features:



APTD-12/22 PLC Controlled Paper Cup Making Machine with automatic lubrication system is our latest machine, which is fully-automatic working from cup wall sealing, bottom sealing, cup rim curling, formed cup counting&stacking in the whole unit. It saves labor cost, energy and working space.

This machine adopts PLC Controlled with touch screen operation, and with automatic lubrication system.



Main Technical Parameters:



Model

APTD-12/22

Cup Size

6-22oz, 22oz-32oz

Paper Material

180-500gsm

Running Speed

60-80pcs/min

Max. Cup Size

Top diameter: 105mm
Cup height: 170mm
Bottom diameter: 80mm

Min. Cup Size

Top diameter: 55mm
Cup height: 60mm
Bottom diameter: 45mm

Power Supply

380V or 220V, 50HZ, 3PH

Total Power

9KW

Air Consumption

0.4m3/min

Weight

2500kgs

Dimension

2.8 × 1.6× 1.6m
