AC single phase 2kw gasoline generator

Specifications

4-stroke, single cylinder with air-cooled
Recoil and hand-operated

Yancheng Jiangyang Foreign Trade Engine Co.Ltd is in Yancheng city,Jiangsu  province, China.



SPECIFICATIONS:

Model		JY1200	JY1500	JY2000	JY2500	JY3000
Generator	Type	Brush, Brushless, Single-phase		Brush, Single-phase
	Voltage Regulate	AVR/Capacitor		AVR
	Frequency (Hz)
	Rated AC Voltage (V)
	Rated AC Output (KVA)	1.0/1.1	1.1/1.3	1.5/1.8	2.0/2.2	2.5/3.0
	Max. AC Output (KVA)	1.1/1.2	1.3/1.5	1.7/2.0	2.2/2.5	2.8/3.53
	Power Factor
Model		JF154	JF156	JF168	JF200	JF200
Engine	Type	4-stroke, single cylinder  with air-cooled		OHV Forced Air-cooled 4-stroke
	Bore x Stroke (mm)	54x38	56x40	68x45	68x54
	Displacement (ml)	86.5	98.5	163	196
	Max. Output (HP/rpm)	2.4/3600	3.0/3600	5.5/3600	6.5/3600
	Fuel	Unleaded Gasoline
	Fuel Tank Capacity (L)	5		15
	Continuous Operating Hours (h)	15		13		11
	Oil	SF or Higher Grade
	Oil Capacity (L)	0.6
	Ignition System	T.C.I.
	Starting System	Recoil and hand-operated		Recoil and hand-operated/Electric start
	Noise Level (7m) dB (A)			67
Standard  Features	Fuel gauge	0		0	0	0
	Voltmeter	0		0	0	0
	AC Circuit Breaker	0		0	0	0
	Engine Switch	0		0	0	0
	AC Socket	0		0	0	0
Optional  Features	DC Output	+		+	+	+
	DC Circuit Breaker	+		+	+	+
	Pilot Light	+		+	+	+
Package  Dimensions	Dimensions (LxWxH)(mm)	480x410x425		600x450x470
	Gross Weight(kg)	28	29	41	42	52
	Net Weight(kg)	31	32	39	40	48
	20/40 FT unit	450/960		225/475
NOTE:"0"=with "+"=as request "-"=without  Specifications subject to change without notice



Product show

Package and shipping



Package detail

Ofiice

Our factory owns the firstrate inspection equipment,high technology and over 20 years’experience in manufacturing diesel engine from 3hp to 33hp and various kinds of generating set from 0.5kw to 1500kw, We also supply water pump set, sprayers,alternator,gasoline engine,tractors and spare parts related.

Warmly welcome you and your company to operate with us for the prosperity future.
