Gasoline Engine JY2500

Name: Gasoline Engine JY2500
Brand: Jiangyang
SKU: 108512121
Availability: InStock

US$ 120 - 160 MOQ: 225 Cartons

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Jiangyang

Model Number:

JY2500

Yancheng Jiangyang Foreign Trade Engine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Jiangyang

Model Number JY2500

Output Type AC Single Phase

Speed 3600

Frequency 50/60 HZ

Rated Power 2KW

Rated Voltage 110/120/220/230/240V

Specifications

EPA/CARB/CE APPROVED

Model		JY1200	JY1500	JY2000	JY2500	JY3000
Generator	Type	Brush, Brushless, Single-phase		Brush, Single-phase
	Voltage Regulate	AVR/Capacitor		AVR
	Frequency (Hz)
	Rated AC Voltage (V)
	Rated AC Output (KVA)	1.0/1.1	1.1/1.3	1.5/1.8	2.0/2.2	2.5/3.0
	Max. AC Output (KVA)	1.1/1.2	1.3/1.5	1.7/2.0	2.2/2.5	2.8/3.53
	Power Factor
Model		JF154	JF156	JF168	JF200	JF200
Engine	Type	4-stroke, single cylinder with air-cooled		OHV Forced Air-cooled 4-stroke
	Bore x Stroke (mm)	54x38	56x40	68x45	68x54
	Displacement (ml)	86.5	98.5	163	196
	Max. Output (HP/rpm)	2.4/3600	3.0/3600	5.5/3600	6.5/3600
	Fuel	Unleaded Gasoline
	Fuel Tank Capacity (L)	5		15
	Continuous Operating Hours (h)	15		13		11
	Oil	SF or Higher Grade
	Oil Capacity (L)	0.6
	Ignition System	T.C.I.
	Starting System	Recoil and hand-operated		Recoil and hand-operated/Electric start
	Noise Level (7m) dB (A)			67
Standard Features	Fuel gauge	0		0	0	0
	Voltmeter	0		0	0	0
	AC Circuit Breaker	0		0	0	0
	Engine Switch	0		0	0	0
	AC Socket	0		0	0	0
Optional Features	DC Output	+		+	+	+
	DC Circuit Breaker	+		+	+	+
	Pilot Light	+		+	+	+
Package Dimensions	Dimensions (LxWxH)(mm)	480x410x425		600x450x470
	Gross Weight(kg)	28	29	41	42	52
	Net Weight(kg)	31	32	39	40	48
	20/40 FT unit	450/960		225/475
NOTE:"0"=with "+"=as request "-"=without Specifications subject to change without notice
