Help CenterPvc Jacket Copper Conductor Indoor 2 Pair Telephone Cable
Related Products
-
Underground Jelly Filled Multipair Cat3 Telephone Cable OutdoorUS$ 0.1 - 2.5MOQ: 20000 Meters -
Supplier UTP Copper Conductor Cat3 Muti-core Telephone CableUS$ 0.1 - 2.5MOQ: 20000 Meters
-
Communication Application High Speed Indoor Underground Telephone CableUS$ 0.1 - 2.5MOQ: 20000 Meters
-
China Supplier Qualified Professional Rj9 Telephone CableUS$ 0.1 - 2.5MOQ: 20000 Meters
-
MultiPair Telephone Cable Communication Cable for TelephoneUS$ 0.1 - 2.5MOQ: 20000 Meters
Henan billion net Photoelectric Technology Co., Ltd is the leading cable manufacturer in China. Cables have been our business for 2 yeas. We offer cat 7 lan cable so your customers can enjoy ultra-fast networking, Our other products cover more than 100 types of CAT6A, CAT6, CAT5E, RVV ,BV,RG ,Telephone wire, Speaker wire ,Alarm cable and so on ,
We are located at Tanghe, Henan province. eleven production lines in our ISO 9001:2008-certified 20,000 square meters factory help us fill orders for buyers in the Europe,America,Asia,Australia, and other countries. and mort than 200 employees make delivery in 20 days possible.
We turn out up to 50 million meters of cable per year, High quality standards and reliable delivery schedules are both very important to our customers. When standards apply (EIA/TIA, ISO ,ROHS, CE, UL, ETL and so on) all products will be 100%compliant .email us today.
indoor 2 pair telephone cable
| Norminal Cross-section | Wire core Structure No/mm | Insulation Norminal Thickness mm | Sheath Norminal Thickness mm | Calculation Outer Diameter mm | Product Approximated Weight Kg/km |
| 1x2x0.5 | 0.5 | 0.22 | 0.6 | 3.4 | 14 |
| 2x2x0.5 | 0.5 | 0.22 | 0.6 | 4.2 | 26 |
| 3x2x0.5 | 0.5 | 0.22 | 0.6 | 4.8 | 29.7 |
| 4x2x0.5 | 0.5 | 0.22 | 0.6 | 5.5 | 37.5 |
| 8x2x0.5 | 0.5 | 0.22 | 0.7 | 7 | 58 |
| 16x2x0.5 | 0.5 | 0.22 | 0.8 | 9.6 | 105 |
| 25x2x0.5 | 0.5 | 0.22 | 1.2 | 11.5 | 167 |
Specifications:
1, Solid BC conductor;
2, HDPE insulated;
3, Black PE jacket;
4, CE, RoHS & ISO9001: 2001 certified;
5, OEM is acceptable.
Specification of 25 pairs outdoor telephone cable
1) CONDUCTOR
* Raw material of the conductor: Solid bare copper
* Conductor Dia.: 0.48± 0.003mm (23AWG)
2) INSULATION
* Raw material of the conductor: HDPE
* Quantity: 4 twisted pairs
Blue/white-blue; Green/white-green;
Orange/white-green; Brown/white-brown;
* Insulation Dia.: 0.91± 0.005mm
* Average thickness: 0.215 mm
* Minimum point thickness: 0.2125mm
3) Separator: PE tape
4) Cable tie: PP
5) Rip cord
6) SHEATH
* Sheath material: PE
* Nominal Dia.: 13.0 ± 0.2mm
* Average thickness: 1.0mm
* Minimum point thickness: 0.90mm
More cables & Products
Cables:
1) 75 ohm Coaxial Cable RG6, RG59, RG11;
2) 50 ohm Coaxial Cable RG174, RG58, RG8, RG213, RG214;
3) Siamese CCTV Cable RG59+2C, KX6+2C, RG6+2C;
4) Combo Coaxial Cable RG6+Cat5e, RG6+CAT5E+Messenger etc;
5) LAN Cable/Network Cable UTP/FTP Cat5e, Cat6, Jumper Cable;
6) 1 pair/2 pairs Telephone Cable;
7) Security Alarm Cable, Fire Alarm Cable, Speaker Cable;
8) Optical Fiber Cable (GYXTY, GYXTW, ADSS, FTHH etc.);
9) 50 ohm RF Feeder Cable 1/4"S, 3/8"S, 1/2"S, 1/2", 7/8", 1-1/4", 1-5/8".
Factory Shows:
1.We have a very strict inspection team to check the quality of goods,can provide you the high quality products.
2.we can reply you at first time when you send a email and inquiry to us,and we are very patient to answer every
questions that enquiring by you
3.We have our own factory,can provide you the competitive price.
4.we accept OEM &ODM
If you have any questions,please feel free to contact us at any time.
1.HOW ABOUT OUR QUALITY?
We have our own factory to manufacture the cables and wires,we can control the quality by our self,and we also have a professional quality inspection team,so please rest assured for our quality.
2.HOW ABOUT THE SAMPLE FEE?
Sometimes we can provide a free sample if you are cooperate with us for many time,or if you are sincerely cooperate with us.
3.HOW ABOUT OUR DELIVERY TIME?
Usually,our delivery time is 15-30 days after all the details confirmed.
