Full-automatic Rolled Paper Cutting Machine

Full-automatic Rolled Paper Cutting Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Toilet Tissue
Processing Type:
Cutting Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen port China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Toilet Tissue
Processing Type Cutting Machine
Place of Origin Fujian, China
Brand Name HUAXUN
Model Number HX-Z200
Voltage 380V,50HZ, 3 phases, 380V,50HZ,3 phases
Power(W) 6.77KW
Dimension(L*W*H) 6.9*1.72*1.92m
Weight 2 tons, 2 tons
Certification CE
Warranty 1 year, 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Accurate cutting
2.High production speed.
3.Equipped with full-automatic programmable controller.
4.Safe guarantee
Log saw



HX-Z200 Full-automatic Log Saw Cutting Machine (Full-automatic Rolled Paper Cutting Machine)



Equipment Function and Configuration:

1. This machine is special equipment for cutting rolled toilet paper and rolled kitchen paper. Production operation is simple, product cut is trim, and production speed is high.

2. Adopts programmable controller to automatically control production. Automatic reset, push roll, cut. The roll-cutting length, cutting period can be adjustable.
3. Automatically check rolled paper head, automatically ablate the untidy and eliminate waste.

4. It's equipped with touch screen man-machine dialogue to control the operation, production parameter and trouble is clear to see, operation is simple.
5. Photoelectric inspecting, servo driving, pneumatic component and bearing cutter, etc uses good quality product.
6. Having automatic blade grinding device. Accuracy of blade-grinding is high. Safety protection switch is on the side door. Equipment automatically stop when door is opened.



Main technical parameter



Paper roll length 1500~2000mm(vary according to length provided by client)
Paper roll diameter φ100~φ120mm (can be decided by customer): two lanes, if above this scope, there will be just one lane.
Production speed  cutting times 80~100 times/minute * 2 rolls/times
Equipment power 6.77KW(380V, 50HZ, 3 phase)
Equipment weight about 2 Tons
Equipment overall size(L*W*H) 6.9*1.72*1.92m





 Full-automatic rolled paper cutting machine Full-automatic rolled paper cutting machine



Full-automatic rolled paper cutting machine



 Full-automatic rolled paper cutting machine

  Full-automatic rolled paper cutting machine
