Help CenterCrusher Wet Pan Mill for Mine
Related Products
-
Crusher Wet Pan Mill for Gold MineUS$ 6,500 - 8,000MOQ: 1 Set -
2014 Mineral Separator 1200B Wet Pan Mill for Gold MineUS$ 6,500 - 7,500MOQ: 1 Set
-
Mineral Separator Wear-resisting China Wet Pan Mill For Gold MineUS$ 6,500 - 7,500MOQ: 1 Set
-
MINE MILL1200B Wet Pan Mill for Gold MineUS$ 6,500 - 7,500MOQ: 1 Set
-
Wet Pan Mill for Gold MineUS$ 6,500 - 7,500MOQ: 1 Set
Specifications
Easy installationEasy operation
Long use life
ISO 9001:2000
Working Principles of Wet Pan Mill:
1.When inputting gold sand into the rolling drum, the rollers compress the sand over and over into tiny particles.
2.Please put in 5 kg mercury at first, the mercury can absorb the gold or other metals.
3.At last, use a high-density red cloth to wrap mercury up.
4.Then squeeze it, the mercury will be pressed out and pure gold stayed.
5.As to the large capacity, we can use mercury shaking machine and mercury steamer to replace the manual work.
Model |
Specification |
Max Input size(mm) |
Rotate Speed (r/min) |
Powder(kw) |
Weight(t) |
1600A |
1600×400×200×500±20mm |
3cm |
20-22 |
25KW |
14.5 |
1500A |
1500×350×200×460±20mm |
20-22 |
22KW |
13.3 |
|
1500B |
1500×350×150×460±20mm |
20-22 |
22KW |
12.3 |
|
1500C |
1500×300×150×420±20mm |
20-22 |
22KW |
11.3 |
|
1400A |
1400×250×150×350±20mm |
16-18 |
18.5kw |
8.5 |
|
1400B |
1400×250×150×350±20mm |
21-23 |
18.5kw |
8.5 |
|
1350A |
1350×250×150×350±20mm |
16-18 |
18.5kw |
8 |
|
1350B |
1350×250×150×350±20mm |
21-23 |
18.5kw |
8 |
|
1300A |
1300×250×150×350±20mm |
16-18 |
15kw |
7.5 |
|
1300B |
1300×250×150×350±20mm |
21-23 |
15kw |
7.5 |
|
1200A |
1200×200×80×250±20mm |
17-19 |
7.5kw |
5.5 |
|
1200B |
1200×180×80×250±20mm |
23-25 |
7.5kw |
5.5 |
|
1100A |
1100×200×80×250±20mm |
17-19 |
7.5kw |
5 |
|
1100B |
1100×180×80×250±20mm |
23-25 |
7.5kw |
5 |
|
1000 |
1000×180×80×250±20mm |
13-15 |
5.5kw |
4.5 |
