MiMA 4-Direction Battery Reach Truck

Name: MiMA 4-Direction Battery Reach Truck
Brand: MIMA
SKU: 108464883
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

China

Brand Name:

MIMA

Hefei Banyitong Science & Technology Developing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Nanjing Port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin China

Brand Name MIMA

Model Number TFB20-60

Type Other

Power Souce AC Motor

Rated Loading Capacity 2000kg

Max. Lifting Height 6000mm

Min. Lifting Height 35mm

Fork Length 1070mm

Fork Width 650mm

Certification ISO9001:2008

Specifications

MiMA 4-Direction battery reach truck TFB
Model TFB
Loading capacity: 1.5-2.5ton
Lifting height: 3000mm to 7200mm

MiMA 4-Direction battery reach truck

1	Model	TFB15	TFB20
2	Loading capacity Kg	1500	2000
3	Loading center mm	500	500
4	Lifting height mm	3000	300
5	Mast inclination deg	3/5	3/5
6	Wheel type	Polyurethane solid wheel
7	Mast forwarding length mm	630	685
8	Fork size mm	1070×100×35	1070×100×45
9	Fork spread	220-662	247-780
10	Overall length(mast closed) mm	2333	2470
11	Frame length mm	1836	1836
12	Overall width mm	1514	1682
13	Overall height(mast closed) mm	2260	2260
14	Overall height(fork rasied) mm	3885	3885
15	Top support protection height mm	2260	2260
16	Free lifting height mm	100	100
17	Drving speed (Load/ Unload) km/h	7.5/8.5	7.5/8.5
18	Driving speed(side) km/h	5	5
19	Lifting speed Load/Unload mm/s	117/243	117/243
20	Driving wheel mm	Φ343×108	Φ343×108
21	Front wheel mm	Φ267×114	Φ267×114
22	Balance wheel mm	Φ180×76	Φ180×76
23	Ground clearance mm	80	80
24	Service brake	Eletromagnetic
25	Parking brake	Eletromagnetic
26	Battery Ah	48V/300Ah	48V/400Ah
27	Charger A	48V/40A	48V/50A
28	Driving motor Kw	5.5(AC)	5.5(AC)
29	Lifting motor Kw	6.3	7.5
30	Total weight(with battery) Kg	2600	3480
