Specifications
Newest /very popularFlat working stable full of dots to absorb smoke very well.
two heads
4000 hours life laser tube.
Applicable industries
Plastic and rubber industry, ads/crafts/presents industry.strument/machine componnents,leather cloth industry. Advertising logo signs, gifts, crystal ornaments, paper cutting techniques, relief, wood carving Jane. Printing plate, leather clothing, embroidery, decoration, frame making and other industries.
Feathures
1.Supports all kinds CAD professional drawing software,avoide the trouble of exchanging graphs.
2.The warming cooling case ensure that the machine works safely.
3.Special aluminum table reduces the damage to materials by reflected light.
4.Large memory capacity &possible offline work.
5.It ids applicable for cutting and engraving of non-metal materials and mainly focus on the former.Acrylics of 20mm can be cut and result comes good.
6.Adopt slowdown composition and deceletrade stabler design Cutting organic product good effect ,material put into and don't cut out.Can be used to advertising engraving and contruction molds industries.
Laser Generator |
Hermetic and detached CO2 laser tube |
Laser Power |
60w /80w /100w/150w |
Work area |
1400*1000mm |
Positioning Precision |
±0.01mm |
Cooling Mode |
Circulating-water-cooling |
Machine Control and Drive |
Speedy DSP controlling, stepper motor |
Power Adjustment |
0-100% controlling, no segment and adjusting by software |
Controlling Software Language |
English, Simplified Chinese, Traditional Chinese and procuring of multi-languages |
Machine Color |
grey/Red , Orange/Grey |
Minimum Character |
Chinese character 1.5mm, crisscross-row 1mm |
Max Power |
≤1200w |
Up-down Range of Working Table |
50mm |
Optional Equipment |
Rotary attachment |
Engraving Speed |
1200mm/s |
Cutting Speed |
600mm/s |
Laser energy control |
1-100% software setting |
Interface |
LCD Screen and USB interface |
Working Voltage |
AC220V ±10%,50Hz |
Running Environment |
0-45°, Humidity: 5%-95% |
...
