Help CenterDW 1280 Laser Cutting Machne
Related Products
-
DW Laser Machine for GarmentUS$ 3,500 - 6,200MOQ: 1 Set -
DW Marble Jade Laser Engraving MachineUS$ 3,500 - 6,300MOQ: 1 Set
-
Laser Cutting Engraving Machine DWUS$ 3,500 - 5,500MOQ: 1 Set
-
DW CNC Cutting Machine for StoneUS$ 7,000 - 9,000MOQ: 1 Set
-
DW 1613 Laser Engraving MachineUS$ 3,000 - 6,000MOQ: 1 Set
Laser Generator |
Hermetic and detached CO2 laser tube |
Laser Power |
60w /80w /100w/150w/180w |
Work area |
1200*800mm |
Positioning Precision |
±0.01mm |
Cooling Mode |
Circulating-water-cooling |
Machine Control and Drive |
Speedy DSP controlling, stepper motor |
Power Adjustment |
0-100% controlling, no segment and adjusting by software |
Controlling Software Language |
English, Simplified Chinese, Traditional Chinese and procuring of multi-languages |
Machine Color |
grey/Red , Orange/Grey |
Minimum Character |
Chinese character 1.5mm, crisscross-row 1mm |
Max Power |
≤1200w |
Up-down Range of Working Table |
320mm |
Optional Equipment |
Rotary attachment |
Engraving Speed |
1200mm/s |
Cutting Speed |
600mm/s |
Color separation |
yes |
Laser energy control |
1-100% software setting |
Drive system |
High precision 3-phase stepper motor |
Laser output contro |
0~100% set by software |
Option |
Up & down table honeycomb worktable rotary device red dot position system auto-focus device |
Interface |
LCD Screen and USB interface |
Working Voltage |
AC220V ±10%,50Hz |
Running Environment |
0-45°, Humidity: 5%-95% |
Features:
1.The structure of the machine is more compact and more reasonable, the electric performance steady; The type of the machine has double efficacy of high-speed engraving and high-speed cutting, the precision is high.
2.The import guide rail equipped with the machine runs steadily, the depth of engraving can be adjusted automatically. The scrap left after engraving is only a little; The verge after cutting has no burr and does not need to polish.
4.Reasonable Gantry Structure, stable laser path. Our solid laser cutting machine adopts gantry structure, cast cross beam, the whole structure is very firm, and it changes the precious cantilever formation, has smaller body, lighter weight, durable structure and high precision.
5.our solid laser cutting machine uses mechanical following cutting head from the USA. Cutting head laser nozzle locking ring touches the metal sheet materials surface, cutting head moves up and down, and it can achieve same focal cutting.
6.the combination of high precision ballscrews drive system and advanced automatic feeding material system.
....
