Help CenterDW1813 Laser Cutting Machine
Related Products
Specification
Laser-type: Hermetic and detached CO2 laser tube
Laser-power: ( 80W / 100W/ 150W/180W for option )
Cooling Mode: Circulating-water-cooling
Power Adjustment: 0-100% controlling, no segment and adjusting by software
Machine Control : Speedy DSP controlling
Driver: step motor
Max Engraving Speed: 1000mm/s
Max Cutting Speed: 300mm/s
Repeating Location: ±0.01mm
Minimum Character: Chinese character 1.5mm, crisscross-row 1mm
Gross Power: < 3000W
Adjustable Up-down Distance of Laser Head: 30mm
Working Travel Area: 1300*1800mm
Table Area : 1850*1350mm
Working Voltage: AC220V ±10%,50Hz
Working Environment Temperature: 0-45°, Humidity: 5%-95%, and congeal-water removed
Controlling Software Language: English, Simplified Chinese, Traditional Chinese, and procuring of multi-languages
Dictate Format: *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.al,*las, Support AutoCAD,CoreDraw direct outputting
Packaging: Wooden box
Gross Weight: 860 kg
Machine Color: Red/white White/grey Blue /white yellow/white
Delivery Time: Within 20 days ( after the deposit)
Optional Equipment:
Water-cooling unit CW3200 / CW5000
Red-light position
Honeycomb worktable
DSP Off-line operation with usb flash
Applicable materials: wood, bamboo, jade, marble, organic glass, crystal, plastic, garments, paper, leather,textile, rubber, ceramic, glass and other nonmetal materials.
Applicable industries: advertisement, arts and crafts, leather, toys, garments, model , building upholster, computerized embroidery and clipping, packaging and paper industry.
Guarantee & Aftersales Service:
Comprehensive guarantee for half year
24-hour technical support by email or calling
User-friendly English manual for machine using and maintaining
You may get support from by calling +86 0-18653133265 from 8:00AM to 5:00PM Beijing Time or by emailing. We will reply within 18 hours
....
