Help CenterDW-1280 Laser Cutting Machine
Related Products
Specifications
DSP control system , used for engraving and cutting,laser tube power 80w-150w for option ,import strait guide axis.
|
DW-1280 Laser Engraving and Cutting Machine |
Machine Performance: | |
Laser-type |
Hermetic and detached CO2 laser tube |
Laser-power |
60W (80W ,100w,150w ,180w for option) |
Cooling Mode |
Circulating-water-cooling |
Power Adjustment |
0-100% controlling, no segment and adjusting by software |
Machine Control and Drive |
Speedy DSP controlling, stepper motor |
Max Engraving Speed |
1200mm/s |
Max Cutting Speed |
500mm/s |
Repeating Location |
±0.01mm |
Minimum Character |
Chinese character 1.5mm, crisscross-row 1mm |
Max Power |
<1500W |
Adjustable Up-down Distance of Laser Head |
30mm |
Working Travel Area |
1200*800mm, 1200mm width with infinity material-feeding |
Table Area |
1250*850mm |
Up-down Range of Working Table |
360mm |
Working Voltage |
AC220V 50Hz |
Working Environment |
Temperature: 0-45, Humidity: 5%-95%, and congeal-water removed |
Controlling Software Language |
English, Simplified Chinese, Traditional Chinese and procuring of multi-languages |
Dictate Format |
*.plt,*.dst,*.dxf,*.bmp,*.dwg,*.al,*las, Support AutoCAD,CoreDraw direct outputting |
Packaging |
Wooden box |
Machine Color |
orange/grey |
Delivery Time |
12 working days |
Payment |
T/T |
Optional Equipment |
Rotary attachment |
|
Motorized up-down table |
|
Water-cooling unit |
|
Red-light position |
|
Vacuum table |
|
DSP Off-line operation with usb flash |
Applicable materials: wood, bamboo, jade, marble, organic glass, crystal,
plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials.
Applicable industries: advertisement, arts and crafts, leather, toys, garments, model ,
building upholster, computerized embroidery and clipping, packaging and paper industry.
Guarantee & Aftersales Service:
Laser tube 2400 hours working time
Comprehensive guarantee for half year
24-hour technical support by email or calling
User-friendly English manual for machine using and maintaining
You may get support from by calling +86 531 88275005 from 8:00AM to 5:00PM Beijing Time
or by emailing. We will reply within 18 hours.
....
