Electric Forklift Truck

Name: Electric Forklift Truck
Brand: MIMA
SKU: 108452293

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New, New

Place of Origin:

Anhui, China

Brand Name:

MIMA

Hefei Banyitong Science & Technology Developing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

As per requirement

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Anhui, China

Brand Name MIMA

Model Number TK

Power Souce AC Motor

Rated Loading Capacity 1.5-2.0T

Max. Lifting Height 3000MM

Min. Lifting Height 150MM

Fork Length 1070

Fork Width 100

Overall Dimensions 3420*1160*2015

Specifications

confortable, battery capacity is powerful, quality battery, CURTIS controller, DC/AC optional

Description	4-Wheel electric forklift
Model	TK20-30 AC	TK15-30 AC
Load capacity Kg	2000	1500
Load center mm	500	500
Lifting height mm	3000	3000
Tilting angle (forward- backward) deg	6/12	6/12
Wheel type	Pneumatic	Pneumatic
Wheel (x=driving wheel)	2x/2	2x/2
Fork size (LxWxT)mm	1070x100x45	1070x100x45
Fork spread mm	220~1000	220-960
Overall length(with forks) mm	3420	3085
Overall width mm	1150	1070
Overall height mast closed mm	2015	2125
Overall height fork raised(with backrest) mm	4050	4050
Overhead guard height mm	2207	2205
Outside turning radius mm	2093	1902
Min. intersecting aisle mm (1000*1200 pallet)	3748	3501
Max. walking speeds (Loaded/ Unloaded) Km/h	12.5/13.5	10/11
Lifting speeds (Loaded/ Unloaded) mm/s	149/285	170/301
Grade abitity (Loaded/ Unloaded) %	10/15	10/15
Total weight( with battery) Kg	3920	3226
Front tire	7.00-12-12PR	6.50-10-10PR
Rear tire	18x7-8-14PR	5.00-8-10PR
Min. under-clearance mm	125	125
Service brake	hydraulic	hydraulic
Parking brake	mechanical	mechanical
Battery V/Ah	48/630	48/440
Driving motor Kw AC	11	8
Lifting motor Kw DC	10	7.5
