Help CenterForklift Clamp TK450
US$ 20,000 - 80,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Anhui, China
Brand Name:
MIMA
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Forklift Paper Roll Clamp TK450US$ 20,000 - 80,000MOQ: 1 Unit -
30 Ton Forklift TK4135US$ 1,000 - 200,000MOQ: 1 Unit
-
Tractor 3-point Forklift TK315US$ 10,000 - 30,000MOQ: 1 Unit
-
MIMA Brand New Forklift TK315US$ 10,000 - 30,000MOQ: 1 Unit
-
Forklift Made in China TKAUS$ 10,000 - 20,000MOQ: 1 Unit
Condition
New
Place of Origin
Anhui, China
Brand Name
MIMA
Model Number
TK450
Type
Other, 4-wheel forklift
Power Souce
AC Motor
Rated Loading Capacity
5000kg
Max. Lifting Height
6000mm
Min. Lifting Height
2500mm
Fork Length
1070mm
Fork Width
150mm
Overall Dimensions
4020*1500*2320mm
Certification
SGS
After-sales Service Provided
Overseas third-party support available
Specifications
forklift clamp,TK450series;with 5T load capacity;
full AC electric forklifts;
Easy Maintenance;
Forklift clamp;
TK450 with Full AC power;easy maintenance;
The rear steering have high reliablity;double pump can provide a smooth continuous regenerative braking;
With imported electric controller;smart turning radius;
Load Capacity:5T,8T,Max Lift height :6000mm;
Options: cold storage system,side shift,clamp,rotator,positioner,push/pull etc attachments;
|
MODEL NO. |
TK450 | ||
| Standard | Power Type | Battery | |
| Operate Type | seated | ||
| Rated Capacity | Q(kg) | 5000 | |
| Load center | C(mm) | 500 | |
| T & y R r I e m |
Wheel Type-Front/Rear | ||
| Front Wheel | 21×8-9 | ||
| Front Rim | 9.75-15 | ||
| Rear Wheel | 21×8-9 | ||
| Rear Rim | 6.00E-09 | ||
| Tyres No. -front/rear (X=Drive wheel) | 2X / 2 | ||
| D i m e n s i o n |
Fork Tilt Angle----Upward/Downward--deg. | α/β(º) | 6/8 |
| Height-Overhead guard--mm | h6(mm) | 2320 | |
| Height--seat to overhead guard | h7(mm) | 1050 | |
| Mast Min Ground Clearance | h8(mm) | 120 | |
| Ground Clearance-center of front&rear axle | h9(mm) | 145 | |
| Overall Length | 11(mm) | 4020 | |
| Length-to Fork Face | 12(mm) | 2950 | |
| Overall Width | b1/b2(mm) | 1500/1340 | |
| Tread Front/rear | b3/b4(mm) | 1183/1090 | |
| Fork Dimensions | mm | 1070*150*50 | |
| Width across forks | b5(mm) | 320-1360 | |
| Aisle width for pallet 1000*1200 | Ast(mm) | 4310 | |
| Aisle with for pallet 800*1000-transverse travel | Ast(mm) | 4110 | |
| Trurning radius | Wa(mm) | 2600 | |
| P o w e r |
Drive Motor type | AC | |
| Driving Motor (S2 60) | kw | 9.1*2 | |
| Lift motor type | AC | ||
| Lift Motor (S3 15%) | kw | 22 | |
| Battery V/AH | V/AH | 80/800 | |
| Weight | Battery | kg | 2100 |
| Service Weight | kg | 7450 | |
