Best Electric Reactor Price, ac Input Reactor, Harmonic Filter Reactor
- Shanghai port or any port of China
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Type | Other, Power | Place of Origin | China | |
| Brand Name | Bocheng | Model Number | CKSG-0.7/0.45-7% | |
| Voltage | 450V | Dimension(L*W*H) | 180X120X180 | |
| Weight | 15kg~40kg | Certification | CE ISO | |
| Warranty | 2 Years | After-sales Service Provided | No overseas service provided |
Product Description
Best electric reactor price, ac input reactor, harmonic filter reactor
450V/480V 7%reactance rate
Reactor type | Matched capacitance | Insulation grade | Dimension mm |
CKSG-0.35/0.45-7% | 5 | F | 150X110X160 |
CKSG-0.525/0.45-7% | 7.5 | F | 150X110X160 |
CKSG-0.7/0.45-7% | 10 | F | 180X120X180 |
CKSG-0.875/0.45-7% | 12.5 | F | 180X120X180 |
CKSG-1.05/0.45-7% | 15 | F | 180X120X180 |
CKSG-1.26/0.45-7% | 18 | F | 200X180X205 |
CKSG-1.4/0.45-7% | 20 | F | 200X180X205 |
CKSG-1.75/0.45-7% | 25 | F | 240X190X205 |
CKSG-2.1/0.45-7% | 30 | F | 260X200X205 |
CKSG-2.8/0.45-7% | 40 | F | 260X200X205 |
CKSG3.15/0.45-7% | 45 | F | 260X210X205 |
CKSG-3.5/0.45-7% | 50 | F | 260X210X205 |
CKSG-4.2/0.45-7% | 60 | F | 260X220X210 |
CKSG-4.9/0.45-7% | 70 | F | 260X220X210 |
CKSG-5.6/0.45-7% | 80 | F | 300X240X260 |
CKSG-6.3/0.45-7% | 90 | F | 300X250X260 |
CKSG-7.0/0.45-7% | 100 | F | 320X250X260 |
480V/525V 14%reactance rate
| Reactor type | Matched capacitance | Insulation grade | Dimension mm |
CKSG-0.7/0.525-10% | 5 | F | 180X120X180 |
CKSG-1.05/0.525-14% | 7.5 | F | 180X120X180 |
CKSG-1.4/0.525-14% | 10 | F | 200X180X205 |
CKSG-1.75/0.525-14% | 12.5 | F | 200X190X205 |
CKSG-2.1/0.525-14% | 15 | F | 240X190X205 |
CKSG-2.52/0.525-14% | 18 | F | 260X200X205 |
CKSG-2.8/0.525-14% | 20 | F | 260X200X205 |
CKSG-3.5/0.525-14% | 25 | F | 260X210X205 |
CKSG-4.2/0.525-14% | 30 | F | 260X220X210 |
CKSG-5.6/0.525-14% | 40 | F | 300X240X260 |
CKSG-6.3/0.525-14% | 45 | F | 300X250X260 |
CKSG-7.0/0.525-14% | 50 | F | 320X250X260 |
CKSG-8.4/0.525-14% | 60 | F | 320X250X270 |
CKSG-9.8/0.525-14% | 70 | F | 320X250X270 |
CKSG-11.2/0.525-14% | 80 | F | 380X240X340 |
CKSG-12.6/0.525-14% | 90 | F | 380X240X340 |
CKSG-14/0.525-14% | 100 | F | 380X260X340 |
A: Generally, we pack our goods in brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 5 to 7 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
