Self- powered wireless doorbell
Tech Intro
Transmitters are used the unique PUSH-RF technology, which is the energy harvesting wireless technology and ultra low power technology. When the button is pressed, it will trigger the micro-generator, the direction of the magnetic circuit in the micro-generator would change. The rapid magnetic flux change leads to an induced voltage, in other words, mechanical energy is changed into electric energy.
RF-transceiver of the receivers receive the wireless signals, microcontroller identifies the signals. If the signals are right and
the pairing between receiver and transmitter is successful, the music chip in the receivers will be triggered; then the loudspeaker plays beautiful music to tell the host there’s a visitor waiting at the door. Mechanical energy is conversed into electrical energy.
Our product is battery-free wireless doorbell with many advantages as follows,
1 self powered button.
2 wireless.
3 waterproof transmitter.
4 inflame retarding receiver
5 25 polyphony ring tones in the receiver.
6 120m long range distance in open area
7 endure low and high temperature
8 433MHz
Self-powered button requires no batteries and other external power. Battery- free will do no harm to environment, more environments, and easier.
Products are wireless, which will be convenient to be installed. No cost of wire, no cost of manual installation.
Our transmitter is waterproof. Soak it in the water for four month, it still works well.
Our receiver can be used safely in the house. .
Receiver is good in sound quality and makes it pleasant for visitors to listen to.
Certificates
CE/ EMC/ LVD /R&TTE/ RoHS/ IPX7
Specifications
Specifications |
Chime |
Transmitter |
Power supply |
AC 100V/220V |
Self-powered |
Operating temperature |
-10°C to +40°C |
-40°C to +60°C |
Range(Open field) |
|
120 meters |
RF Frequency |
433MHz |
|
Sound Level(typical) |
85dBA @3 ft(1m) |
|
Power consumption |
200mW |
|
| ||
Waterproof |
|
Yes |
Color of Indicator light |
Blue, |
|
Plug |
EU |
|
Operating forces |
|
10N |
Dimensions |
68*86*53mm |
46*88*31mm |
Weight |
79g |
80g |
Ring Tone |
25 polyphony ring tones |
|
Operations and Features
Plug in the receiver, and when someone press the transmitter, the receiver will play music and LED flash.
The receiver has been paired to the transmitter at factory, after installation, it’s ready to work.
Short press the round buttonon the receiver, you can change the ring tones.
Double press the round button on the receiver, you can change the volume with three levels, high, middle and low.
Long press the round button on the receiver for 5 seconds, and the LED off, then quickly press the transmitter, you just finished the self-learning setting.
Learn Mode
Long press the round button on the receiver for 5 seconds, until the indicator light is off.
Then press the transmitter twice in 1 minute, the receiver will ring with the indicator light flashing to confirm that the transmitter has been paired to the transmitter. If not, please press the button twice again.
1: No operation in 1 minute or short press the transmitter once, the receiver will exit Learn Mode
2: Maximum of 3 transmitters can be learnt to a single socket.
