Heat Resistant Tinned Copper Wires

Name: Heat Resistant Tinned Copper Wires
Brand: Shen Zhou Special Cable
SKU: 108335403
Availability: InStock

Negotiable MOQ: 1 Kilometer (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hunan, China

Brand Name:

Shen Zhou Special Cable

Model Number:

FFBL FFBLP

Xiangtan Shenzhou Special Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hunan, China

Brand Name Shen Zhou Special Cable

Model Number FFBL FFBLP

Application Other, AIRCRAFT

Conductor Material Other, tin plated copper

Conductor Type Stranded

Insulation Material PTFE

Product Description

Product Name: heat resistant tinned copper wires

Features:

1.tin plated copper conductor core
2.PTFE insulation material
3.aerooil resistant,incombustibility

Specification

Nominal cross section area(mm²)	Core construction Core no./diameter	When 20degree DC resistance ≤ Ω/Km	Maximum Outer diameter of electric wire (mm)		Maximum weight of electric wire kg/km
Nominal cross section area(mm²)	Core construction Core no./diameter	When 20degree DC resistance ≤ Ω/Km	FFBL	FFBLP	FFBL	FFBLP
0.07	7/0.12	280	1.96	2.56	-	-
0.1	7/0.14	205	2.02	2.62	-	-
0.14	7/0.16	140	2.08	2.68	-	-
0.2	7/0.2	100	2.2	2.8	-	-
0.25	7/0.23	80	2.29	2.89	-	-
0.35	7/0.26	58.0	2.38	2.9	8	20
0.5	7/0.3	41.3	2.5	3.1	10	23
0.75	19/0.23	26.8	2.7	3.3	14.0	30
1.0	19/0.26	20.5	3.0	3.6	17	33
1.5	19/0.32	13.3	3.3	4.1	29	61
2.5	49/0.26	8.0	3.8	4.6	35	68
4.0	49/0.32	5.0	4.6	5.4	50	86
6.0	49/0.39	3.3	5.2	6.0	72	110
10.0	84/0.39	2.0	6.7	7.9	131	200
16.0	84/0.40	1.2	7.8	9.0	183	265
25.0	133/0.49	0.8	9.1	11.3	275	365
35.0	133/0.58	0.57	10.7	11.9	375	482
50.0	133/0.68	0.4	12.4	13.6	520	640
70.0	189/0.68	0.3	14.1	15.0	695	820
