Fluoroplastics FEP Insulation Wire--AF

Name: Fluoroplastics FEP Insulation Wire--AF
Brand: JINFENG
SKU: 108335459
Availability: InStock

Negotiable MOQ: 1 Meter (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hunan, China

Brand Name:

JINFENG

Model Number:

AF/AFP

Xiangtan Shenzhou Special Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai/guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hunan, China

Brand Name JINFENG

Model Number AF/AFP

Type Insulated

Application Other, ELECTRIC DEVICE

Conductor Material Copper

Conductor Type Solid

Insulation Material FEP

Detailed Description

Product Name: Fluoroplastics FEP Insulation wire--AF

Usage: electric device and applicance

Features:

1.small cross section area and light weight

2.warm&cold resistant

3.flexible and anti-aging/anti-interference

Specification

Cores×nominal cross section area (mm²)	Core construction Core no./diameter	Maximum Outer diameter of electric wire (mm)								When 20degree DC resistance ≤ Ω/Km
		AF AF-1			AFP AFP-1			AFPE
		ONE CORE	TWO CORE	THREE CORE	ONE CORE	TWO CORE	THREE CORE	ONE CORE	TWO CORE
0.013	7/0.05	0.57	1.14	1.23	1.0	1.8	1.9	1.5	2.3	1400
0.035	7/0.08	0.67	1.34	1.44	1.1	2.0	2.1	1.6	2.5	600
0.05	10/0.08	0.72	1.44	1.55	1.2	2.1	2.2	1.7	2.6	370
0.07	14/0.08	0.75	1.5	1.62	1.3	2.2	2.3	1.8	2.7	260
0.10	21/0.08	0.85	1.7	1.83	1.4	2.4	2.5	1.9	2.9	180
0.12	24/0.08	0.88	1.76	1.90	1.5	2.5	2.7	2.0	3.0	150
0.14	30/0.08	0.9	1.8	1.94	1.5	2.5	2.7	2.0	3.0	125
0.20	42/0.08	1.0	2.0	2.15	1.5	2.7	2.9	2.0	3.2	100
0.25	56/0.08	1.15	2.3	2.48	1.7	3.0	3.2	2.2	3.5	90
0.30	62/0.08	1.18	2.36	2.54	1.7	3.1	3.3	2.2	3.6	70
0.35	75/0.08	1.2	2.40	2.58	1.9	3.2	3.4	2.4	3.7	60
0.40	85/0.08	1.39	2.78	3.0	2.0	3.5	3.7	2.5	4.0	55
0.45	95/0.08	1.45	2.9	3.12	2.1	3.6	3.8	2.6	4.1	50
0.50	105/0.08	1.5	3.0	3.23	2.1	3.7	4.0	2.6	4.2	42

TYPE	cores×nominal cross section area(mm²)	Core construction No./diameter (mm)	Maximum Outer diameter (mm)	When 20degree DC resistance ≤ Ω/Km	Re. weightkg/km
AFSP	2*0.013	7/0.05	1.2	1400	2.56
AFSP	2*0.035	7/0.08	1.5	600	3.85
AFSP	2*0.05	7/0.1	1.9	370	4.32
AFSF	2*0.035	7/0.08	1.9	600	2.9
AFSF	2*0.05	7/0.1	2.1	370	3.4
AFSF	2*0.07	14/0.08	2.8	260	3.8
