Radiation Cross-linking ETFE Wires and Cables

Name: Radiation Cross-linking ETFE Wires and Cables
Brand: Jinfeng
SKU: 108335145
Availability: InStock

Negotiable MOQ: 1 Kilometer (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hunan, China

Brand Name:

Jinfeng

Model Number:

AWG30,28,26,24,22,20,18,16,14,12

Xiangtan Shenzhou Special Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port of China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hunan, China

Brand Name Jinfeng

Model Number AWG30,28,26,24,22,20,18,16,14,12

Type Insulated

Application Other, electric connections

Conductor Material Other, tinned cooper conductor

Conductor Type Solid

Insulation Material Other, X-ETFE

DESCRIPTION

Radiation cross-linking ETFE wires and cables

1.Rated a.c. voltage is up and including 600V;

2.The maximum continuous long-time operating temperature of tinned copper conductor is 150°c,

and those of silver-plated & nickel-plated copper conductor is 200°c.

3.The wires are used as the electric connection of electric equipment and instrument applies.

4.Types and description of wires and cables are given in table 1.

Table1

Type	Description
FJF40Q-X	X-ETFE insulated electrical wires and cables(light weight)
FJF40PQ-X	X-ETFE insulated sreened elecrical wires and cables(light weight)
FJF40PHQ-X	X-ETFE insulated screened,shiled,electrial wires and cables(light weight)

P11----tinned copper conductor knitting screened

p21----silver-plated copper conductor knitting screened

p31----nickel-plated copper conductor knitting screened

H03--- FEP shield

H10---ETFE shield

JH10---X-ETFE shield

5.Specification and construction diemension are given in table2.

Tabler2

No	Nominal area mm2	AWG	Construction	Outer diameter(mm)	Max.weight(kg/km)	Max.d.c.resistance of conductor
						Tinned	Silver-plated	Nickel-plated
1	0.06	30	7/0.10	0.60+-0.05	0.983	356	336	370
2	0.08	28	7/0.12	0.69+-0.05	1.36	225	209	223
3	0.15	26	19/0.10	0.81+-0.05	2.09	136	126	138
4	0.20	24	19/0.12	0.94+-0.05	2.98	86	79.7	85
5	0.30(0.35)	22	19/0.16	1.09+-0.05	4.17	53.1	49.5	52.5
6	0.5(0.6)	20	19/0.20	1.27+-0.05	6.40	32.4	30.2	32.1
7	1.0	18	19/0.26	1.52+-0.05	9.68	20.4	19.0	20
8	1.2	16	19/0.28	1.73+-0.05	12.4	15.8	14.8	15.6
9	2.0	14	19/0.37	2.16+-0.08	19.4	10	9.45	9.84
10	3.0	12	37/0.32	2.62+-0.08	29.3	6.63	6.23	6.50
