Description
Product Name: industrial cable
The allowing bendingradius for the cable should no less than four times than outer diameter
70degree flexible soft cable and wire
Type |
JXN,JXF |
||||||||||
|
Nominal Cross Section Area (mm²) |
Constructure Of Conductor Cores/diameter (mm) |
Average Upper limit of outer diameter(mm) |
Nominal Cross Section Area (mm²) |
Constructure Of Conductor Cores/diameter (mm) |
Average Upper limit of outer diameter(mm) |
||||||
500v |
1000v |
3000v |
6000v |
500v |
1000v |
3000v |
6000v |
||||
0.5 |
16/0.20 |
4.3 |
5.1 |
/ |
/ |
25 |
196/0.40 |
13.7 |
14.6 |
17.8 |
20.6 |
0.75 |
24/0.20 |
4.5 |
5.4 |
/ |
/ |
35 |
276/0.40 |
14.9 |
15.7 |
18.9 |
21.7 |
1.0 |
32/0.20 |
4.7 |
5.5 |
/ |
/ |
50 |
396/0.40 |
17.1 |
17.9 |
20.9 |
23.3 |
1.5 |
30/0.25 |
5.0 |
5.9 |
/ |
/ |
70 |
360/0.50 |
19.6 |
20.5 |
24.0 |
27.0 |
2.5 |
49/0.24 |
6.2 |
7.1 |
10.3 |
13.5 |
95 |
475/0.50 |
21.9 |
22.8 |
26.5 |
28.9 |
4 |
56/0.30 |
6.8 |
7.7 |
11.0 |
14.2 |
120 |
608/0.50 |
24.6 |
25.0 |
28.6 |
30.8 |
6 |
84/0.30 |
7.5 |
8.4 |
12.0 |
15.2 |
150 |
756/0.50 |
/ |
/ |
/ |
33.5 |
10 |
84/0.40 |
10.0 |
10.9 |
14.0 |
16.8 |
185 |
925/0.50 |
/ |
/ |
/ |
33.5 |
16 |
126/0.40 |
11.2 |
12.0 |
15.2 |
18.0 |
240 |
1221/0.50 |
/ |
/ |
/ |
36.5 |
JXN : Copper conductor ,rubber insulated ,nitrile butadiene sheathed, Motor Winding Connection Flexible Cable(wire)
JXF:Copper conductor ,rubber insulated ,neropene sheathed, Motor Winding Connection Flexible Cable(wire)
