FEP Oil-resisitence/acid &alkali-resisitence Flexible Wire

Name: FEP Oil-resisitence/acid &alkali-resisitence Flexible Wire
Brand: Shen Zhou Special Cable
SKU: 108334505
Availability: InStock

Negotiable MOQ: 1 Kilometer (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hunan, China

Brand Name:

Shen Zhou Special Cable

Model Number:

KFHR KFHRP KFHRP-1

Xiangtan Shenzhou Special Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hunan, China

Brand Name Shen Zhou Special Cable

Model Number KFHR KFHRP KFHRP-1

Application Instrumentation

Conductor Material Copper

Insulation Material FEP

Product Description

Product Name : FEP oil-resisitence/acid &alkali-resisitence flexible wire

Product Details:

1.Nominal Voltage :50HZ, AC nominal voltage 380Vor below
2.-50~+70degree
3.puncture test:AC 2000V/2min no breakdown

Application: used for the connection of various of instruments or control device

Feature:when 20degree insulation resistant:≥300MΩ•km

Heat test50°c×4h insulation resistant≥10M Ω•km

cold resistance, oil resistance, acid and alkali resistant, soft, anti-interference

Data Sheet:

Specification cores×cross section area(mm²)	Core construction Core no./diameter	Maximum Outer diameter of electric wire (mm)		When 20degree conductor DC resistance ≤ Ω/Km	Re. weightkg/km
Specification cores×cross section area(mm²)	Core construction Core no./diameter	KFHR	KFHRP KFHRP-1	When 20degree conductor DC resistance ≤ Ω/Km	KFHR	KFHRP KFHRP-1
2×0.35	7/0.26	6.0	7.0	53.5	41.8	71.2
3×0.35		6.4	7.4		47.4	80.4
4×0.35		7.7	8.7		54.6	93.4
5×0.35		8.0	9.0		62.2	102.4
7×0.35		8.4	9.4		78.0	120.0
10×0.35		9.3	10.3		102.2	149.0
12×0.35		10	11.0		113.6	180.7
16×0.35		10.7	11.7		138.5	210.0
19×0.35		11.2	12.4		156.2	231.2
20×0.35		11.4	12.6		164.0	240.5
22×0.35		12	13.2		177.7	257.5
24×0.35		12.5	13.7		190.4	273.9
26×0.35		13.2	14.4		203.1	291.5
32×0.35		14.4	15.6		260.8	356.6
36×0.35		14.8	16.0		284.2	383.4
37×0.35		15	16.2		289.1	414.8
