Stainless Steel Hot Sugaring Tank

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Ningbo /shanghai or any port of China
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	HY
Model Number	Stainless steel Hot And Cold Tanks

Product Description

Specifications

Stainless Steel Hot And Cold Tanks
1.Corrosion resistance
2.Noise elimination
3.SUS304 SUS316L
4.With CE

Stainless Steel Hot And Cold Tanks :

Specifications

1. Storing, heating or sterilizing dairy product, pharmacy,Tomato Paste, etc. 2. Scrapping Stirrer no scorching 3.SUS304/316L

1. Storing, heating or sterilizing dairy product, pharmacy, Tomato Paste, etc. 2. Scrapping Stirrer, no scorching

This equipment is mainly used in the heating, heat preservation, sterilization, cooling, aging and storage of liquid material, during the industries of dairy products, ice cream, pharmacy, chemical industry, cosmetic, and so on.

It is of many advantages of energy conservation, noise elimination, acid-proof, strong productivity, and easily washable and so on.

Parameters:

Specification	500L	600L	1000L	2000L	3000L	4000L	5000L
Heating area(©O)	1.9	2.5	4.5	7.5	8.5	10.5	12
Rotation rate (mph)	36	36	36	36	36	36	36
Power (KW)	0.55	0.75	1.1	1.5	1.5	1.5	2.2

Stainless Steel Hot And Cold Tanks 's Suitable Feilds

1. It is widely used in dairy industry, food, pharmaceutical, chemical, beverage and other industrial departments;

2. To heat, cool, insulate, sterilize processing or store slurry;

3. Especially suitable for pasteurization and insulation of milk, and is the necessary equipment in ice cream production line.

Stainless Steel Hot And Cold Tanks ’s Characteristics

1. Energy saving

2. Corrosion resistance

3. Strong production capacity

4. Easy to clean

5. User-friendly, easy to operate, healthy to store

6. Mirror-polished (roughness Ra≤0.4µm)

7. Adopt SUS304 or SUS316L

Stainless Steel Hot And Cold Tanks ’s Detailed Picture

Stainless Steel Hot And Cold Tanks ' s Technical Parameter

Model	300L	400L	500L	600L	800L	1000L	1500L	2000L	3000L
Diameter(mm)	Φ800	Φ800	Φ900	Φ1000	Φ1000	Φ1000	Φ1200	Φ1300	Φ1600
Height (mm)	600	800	800	800	1000	1220	1220	1500	1500
Working pressure	≤0.09Mpa
Working temperature	<100°C

Notes:

1. The technical parameters of Stainless Steel Hot And Cold Tanks are for reference (in kind prevail), any special requirement, please put forward.

2. The jacket working pressure≤ 0.09Mpa also can be made according to customers’ requirements.

3. Process parameters that need provided: volume, the nature of material,specific requirements, etc.
