Electric Heating Jacketed Kettle(stirring)

Electric Heating Jacketed Kettle(stirring) photo-1
Electric Heating Jacketed Kettle(stirring) photo-2
Electric Heating Jacketed Kettle(stirring) photo-3
Electric Heating Jacketed Kettle(stirring) photo-4
Electric Heating Jacketed Kettle(stirring) photo-5
Electric Heating Jacketed Kettle(stirring) photo-6
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
HUAYOU
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Zhejiang, China
Brand Name HUAYOU
Model Number HY300L-EJ
Type Bean Curd Machine
Weight 154KG
Dimension(L*W*H) 1100*1000*1630mm
Certification CE
Warranty One year
After-sales Service Provided No overseas service provided

Specifications

electric heating jacketed kettle
1.improve quality
2.shorten the time
3.improve working condition

electric heating jacketed kettle

electric heating jacketed kettle(stirring)

Our company 's jacketed kettle is made of SUS304 or SUS316L, it also can according to the customer requirements

electric heating jacketed kettle(stirring)

Electric heating jacketed kettle's heating power is electric

electric heating jacketed kettle(stirring)

It control by the electric cabinet

electric heating jacketed kettle(stirring)

electric heating jacketed kettle(stirring)



electric heating jacketed kettle(stirring)

This tilting type is easy for material pour-out

Tilting jacketed kettle made of acid and heat-resisting stainless steel 304, equipped with a pressure gauge and relief valve, electric cabinet. Equipment is beautiful, easy installation, convenient operation, safe and reliable. Be widely applied in food processing such as candy, medicine, dairy, alcohol, cake, sweetmeat, beverage, can, etc. It can be used to boil soup, cook, stew and porridge in some large restaurants and canteens. It is considered to be the ideal equipment in the area of improving quality, shortening the time and improving working conditions.



300L Tilting jacketed kettle  characteristics



Tilting jacketed kettle has the characteristics of heating efficient, safe and convenient. It is suitable for block material, such as chicken, chicken feet and other granular material.





300L Tilting jacketed kettle  Technical parameters:



Metric volume(L)

50

100

200

300

400

500

600

800

1000

Caliber (mm)

Φ600

Φ700

Φ800

Φ900

Φ1000

Φ1100

Φ1200

Φ1300

Φ1400

Depth of pot(mm)

400

450

530

630

680

730

780

830

900

Heating area(m2)

0.45

0.58

1.12

1.42

1.75

2

2.3

3.2

3.9

Heater Power(kw)

9

9

15

18

18

24

24

27

30

Heat conduction oil(L)

30

36

45

60

70

80

100

200

250

Interlayer work pressure

≤0.09Mpa(can be adapted according to customer requirement)

Mixing speed

36 r/min(can be adapted according to customer requirement)

Mixing power(Kw)

0.55

0.55

0.75

1.1

1.1

1.5

1.5

2.2

2.2
