Industrial Ethernet and wifi sim card router 4g 3g router con slot per sim card

Specifications

1) Cellular Router
2) Single sim
3) LAN RJ45*1+WAN RJ45*1/ LAN RJ45*2
4) Cellular/WAN RJ45/WiFi Client supports cold failover



Product Brief

The H685 series Cellular Router designed for establish a 2G/3G/4G cellular and Wi-Fi wireless network and share a cellular broad band Internet connection. The H685 series Cellular Router enables users to quickly create a secure Wi-Fi (802.11 b/g/n) network and provide access to the Internet using a cellular network. By connect to cellular mobile network; an Internet connection can be accessed and shared virtually anywhere within a wireless broadband network.

E-Lins’ mobile data products are widely used in more than 50 countries and regions, and more than twenty industrial fields, such as power control, water schedule, traffic, oil field, weather forecast, environmental protection, street lamp control, post, bank and many other areas.



Main Feature

Industrial class,with sim card slot

Interface:1 RJ45 LAN Port + I/O port

Optional additional port: RS232 or RS485 port

Band: UMTS HSDPA/HSUPA/HSPA/HSPA+: 2100Mhz or 850/1900/2100Mhz or 850/900/1900/2100Mhz

EDGE/GPRS/GSM: 850/900/1800/1900Mhz

 LTE: 700(B17)/AWS or 800/900/1800/2100/2600MHz or 700(B13)MHz

CDMA/EVDO: 800/1900Mhz, or 450Mhz

VPN(PPTP,L2TP,IPsec,GRE),SNMP

DDNS, DHCP, NAT/NAPT,Web,Auto-dial,always online,watch-dog



Option feature

1) Serial port for DTU feature (Serial to Cellular Gateway)

2) WiFi 802.11b/g/n (working as AP and Bridge Repeater)

3) GPS

4) POE

We have 4G LTE/3G HSPA+/3G HSPA(HSUPA HSDPA)/3G CDMA2000 EVDO version, please contact us freely if the quoted version is not the one you need.



Dual H685 Application Combination type
H685-1	H685-2
Network A	Network B
Network A	Network A
It means H685-1 and H685-2 can be same network, also can be different network. Network A can be any one of GSM/GPRS/EDGE/UMTS/HSDPA/HSUPA/HSPA/HSPA+/4G LTE/CDMA1x/EVDO; Network B can be any one of GSM/GPRS/EDGE/UMTS/HSDPA/HSUPA/HSPA/HSPA+/4G LTE/CDMA1x/EVDO; Please specify with us which network you will use before order.



Typical Diagram for NR685 Router in Wireless M2M





  >>| Industrial Application

Remote Data Monitor and Control

CCTV, security surveillance

Water, gas and oil flow metering and schedule

AMR (automatic meter reading)

Power station monitoring and control Remote POS (point of sale) terminals, ATM,

Traffic signals monitor and control, Traffic info guidance

Oil field, weather forecast, environmental protection, street lamp monitoring and control

Early Warning of Mountain Torrent

Fleet management Power distribution network supervision

Central heating system supervision

Weather station data transmission

Hydrologic data acquisition

Vending machine Telemetry, SCADA

Vehicle logistics and diagnostics controlling

Parking meter and Taxi Monitor

Telecom equipment supervision (Mobile base station, microwave or optical relay station)
