Help Center300/500V PVC Flexible Twisted Cable to BS 6500
Related Products
-
300/500V Copper Pvc Round WireUS$ 0.6 - 9MOQ: 100 Meters -
300/500v Copper Conductor Pvc Round WireUS$ 0.6 - 9MOQ: 100 Meters
-
Copper Flexible WiringUS$ 0.6 - 9MOQ: 100 Meters
-
300/300V PVC Insulated Flexible Twin Flat Cable to BS 6500US$ 0.6 - 9MOQ: 100 Meters
-
300/300V PVC Insulated Flexible Cable to BS 6500US$ 0.6 - 9MOQ: 100 Meters
Specifications
PVC Flexible Twisted cableReference No 2492X
Twisted Twin Flexible Cords
Factory to Customer price
May be you are also interested about
300/300V PVC Insulated Parallel Flexible Cords to BS 6500
300/500V PVC Insulated Twisted Twin Flexible Cords to BS 6500
300/300V PVC Insulated PVC Sheathed Parallel Twin Light Flexible Cords to BS 6500
300/500V Copper conductor PVC insulated flexible wire 3cores
300/500V PVC Insulated Twisted Twin Flexible Cords to BS 6500
300/500v pvc twin flat cable
Why Choose us?
For over 20 years, Zhengzhou Jinyuan Wire and Cable Co., Ltd., as a professional cable manufacturer has been producing customized cable for a wide range of applications based on high quality, excellent service and competitive market prices. This is an elite team with experienced personnel and strong technical support. Our achievements benefit by having access to the largest market for cheap labor and abundant resources in China and our determination to exceed our clients’ expectations.
PRODUCTS & STANDARDS
We can produce more than 2,000 types of cables and wires, such as
Bare Conductor: AAC, AAAC, ACSR, ACSR/AW, ACAR, ACSS, ACSS/AW, Aluminum Clad Steel Wire/Strand, Bare Copper Conductors, Copper Clad Steel Wire/Strand, Copper Clad Aluminum(CCA), Galvanized Steel Wire/Strand, etc.
Overhead Insulated Cable: Covered Line Single Core Cable and Aerial Bundled Cable (ABC). ABC includes Duplex, Triplex, Quadruplex and more Cores Service Drop Cable.
PVC Insulated Wire up to 450/750V
PVC or XLPE Insulated Power Cable from 1kV to 36kV
Control Cable
Welding Cable
Rubber Cable
We can produce cables according to the standards of IEC, ASTM, EN (BS, DIN, NF, etc.), AS/NZ and meet customers’ special requirements.
ACHIEVEMENTS & COMMITMENT
Our cable has been exported to South-East Asia, South Asia, Middle-East, Europe, North and South America, Africa, Australia & New Zealand and so on. Zhengzhou Jinyuan Wire and Cable Co., Ltd.’s commitment is to be recognized as a zero-defect world class manufacturer in cable industry through continuous improvement of our quality, processes, and products, and by our determination to exceed our clients’ expectations.
PVC Flexible Twisted cable
300/500V PVC Insulated Twisted Twin Flexible Cords to BS 6500
Reference No 2492X
Twisted Twin
1.Conductor of high conductivity copper wires insulated with PVC compound.
2.Two cores twisted together.
Size of conductor |
Nominal thickness of insulation
mm |
Mean overall diameter of each core Upper limit
mm |
Approx. net weight per km
kg |
|
|
Nominal cross-sectional area
mm2 |
Number and diameter of wires mm |
|||
0.5 |
16/0.20 |
0.6 |
4.6 |
20 |
0.75 |
24/0.20 |
0.6 |
5.0 |
26 |
1.0 |
32/0.20 |
0.6 |
5.4 |
33 |
